Pneumatic bending machine HRP 300

manualfor plastic profilessemi-automatic

Description
Floor-standing semi-automatic thermoplastic bending machine with double-sided (upper and lower) heating, time-controlled upper frame and 3000 mm working length. Equipped with two digital temperature controllers, one lower heating line and one upper heating line. Supplied as standard with a parallel back gauge and one clamping bar.

Operation and advantages
The HRP series uses digitally controlled heating cables; heating profiles are easy to position and profile cables are height-adjustable. Double-sided heating enables faster processing, reduces internal stress and permits bending of thicker materials including polycarbonate. The pneumatic upper frame has adjustable pressure bars operated by foot pedal and timer. The work surface is heat-resistant and made of multiple adjustable panels with a parallel stop marked in mm/inches. The machine has a modular design prepared for expansion with additional heating profiles and control units and includes two emergency stops.

Applications

• Large-format signage and display fabrication.
• Acrylic furniture and large decorative elements.
• Large prototypes and industrial models for testing and design.
• Production of large plastic components for industrial applications.
• Architectural and construction plastic elements.

Key features

• Working length 3000 mm suitable for large projects.
• Double-sided heating (upper and lower) with digitally controlled heating cables.
• Adjustable digital temperature control (2 control units).
• Height-adjustable heating profiles and easy positioning.
• Pneumatic upper frame with adjustable pressure bars, foot pedal and timer control.
• Parallel back gauge and clamping bar as standard; heat-resistant multi-panel work surface.
• Modular expandability and two emergency stops.

Technical characteristics HRP 300

• Model type: Floor
• Bending method: Manual / semi-automatic operation
• Heating method: Lower and upper (double-sided)
• Lower heating lines: 1 - 4
• Upper heating lines: 1 - 4
• Modular extendable: Yes
• Construction: 1 to 4 lower lines / 1 to 4 upper lines
• Working length: 3.000 mm
• Working thickness: 1 - 12 mm (max. 25 mm depending on material)
• Distance between two bends: 20 - 1.000 mm
• Connection voltage: 400 V
• Power consumption: 2 kW - 8 kW
• Dimensions (LxWxH): 3.390 x 1.300 x 1.720 mm
• Weight: 750 kg
• Standard accessories: Parallel back gauge, 1 clamping bar, foot pedal and timer for upper frame control
