Screw compressor DAS-180LBE

airdiesel enginemobile

Overview
Diesel-powered portable air compressor suitable for industrial and site applications requiring a continuous compressed air supply.

Technical specifications

• Model: DAS-180LBE
• Rated Pressure: 102 psi / 0.7 MPa
• Air Delivery: 5.1 m³/min (180 cfm)
• Air Tank Capacity: 0.039 m³
• Engine: Kubota V2403-K3A
• Fuel: Diesel
• Fuel Consumption: 6.1 L/h
• Tank Capacity: 90 L
• Emission Regulation: Tier 3 (Japanese regulation)
• Dimension (L×W×H): 1,580 × 1,000 × 1,200 mm
• Eco Base Capacity: 132 L
• Weight: 805 kg
• Sound Level (From 7 m): 68 dB

Applications

• Construction site pneumatic tools and breakers
• Sandblasting and surface preparation
• Maintenance operations and mobile workshops
• Industrial shutdowns and remote operations

Operation & maintenance

• Onboard Kubota V2403-K3A diesel engine provides independent power without external electricity
• Fuel consumption 6.1 L/h with 90 L tank for extended runtime; follow manufacturer schedule for maintenance intervals
• Accessible service points for routine inspection, filter replacement and engine maintenance

Compliance & noise

• Complies with Tier 3 Japanese emission regulation
• Measured sound level: 68 dB at 7 m

Dimensions & weight

• Dimensions (L×W×H): 1,580 × 1,000 × 1,200 mm
• Weight: 805 kg
• Eco base capacity: 132 L

Ordering & options

• Contact supplier for available options, transport configuration and spare parts
