Screw compressor DAS-410LBE2

airdiesel engineportable

Overview
The DAS-410LBE2 is a portable diesel-driven air compressor designed for heavy-duty industrial and construction sites. It delivers high airflow with stable pressure control and integrates a Kubota V3800-DI-TI-K3B engine for reliable performance.

Key features

• Air delivery: 11.6 m³/min (410 cfm)
• Rated pressure: 102 psi / 0.7 MPa
• Diesel engine: Kubota V3800-DI-TI-K3B
• Fuel consumption: 13.8 L/h with 170 L tank
• Low sound level: 68 dB at 7 m
• Eco base capacity: 250 L for extended operation

Technical specifications

• Model: DAS-410LBE2
• Rated Pressure: 102 psi / 0.7 MPa
• Air Delivery: 11.6 m³/min (410 cfm)
• Air Tank Capacity: 0.10 m³
• Engine: Kubota V3800-DI-TI-K3B
• Fuel: Diesel
• Fuel Consumption: 13.8 L/h
• Tank Capacity: 170 L
• Emission Regulation: Tier 3 (Japanese regulation)
• Dimension L×W×H: 2,600×1,300×1,400 mm
• Eco Base Capacity: 250 L
• Weight: 1,595 kg
• Sound Level (From 7m): 68 dB

Options
Non-standard options and custom configurations are available to match site requirements (filters, control panels, towing options, etc.).

Applications

• Construction and civil engineering
• Road works and maintenance
• Mining and quarrying operations
• Rental fleets and industrial projects
• Powering pneumatic tools and equipment
