Screw compressor DIS-110VPBairdieselportable
Add to favorites
Compare this product
Characteristics
- Technology
- screw
- Type
- air
- Power source
- diesel
- Portability
- portable
- Applications
- process, construction
- Tank volume
230 l
(60.8 gal)- Pressure
69 bar
(1,000.76 psi)- Weight
2,270 kg
(5,004.5 lb)- Noise level
69 dB
Description
Overview Box-type diesel air compressor designed for industrial and construction applications, providing continuous compressed air delivery for tools and processes.
Brand Denyo
Technical specifications
Model: DIS-110VPB
Rated Pressure: 149 psi / 1.03 MPa
Air Delivery: 12.2 m³/min (431 cfm)
Air Tank Capacity: 0.144 m³
Engine: Isuzu AI-4HK1X
Fuel: Diesel
Fuel Consumption: 18.5 L/h
Tank Capacity: 230 L
Emission Regulation: Tier 3 (Japanese regulation)
Dimensions (L×W×H): 2,970 × 1,410 × 1,630 mm
Weight: 2,270 kg
Sound Level (at 7 m): 69 dB
Options
Non‑standard configurations and accessories available on request (filters, control panels, special piping, shipment preparation).
Technical details
Brand Denyo
Technical specifications
Model: DIS-110VPB
Rated Pressure: 149 psi / 1.03 MPa
Air Delivery: 12.2 m³/min (431 cfm)
Air Tank Capacity: 0.144 m³
Engine: Isuzu AI-4HK1X
Fuel: Diesel
Fuel Consumption: 18.5 L/h
Tank Capacity: 230 L
Emission Regulation: Tier 3 (Japanese regulation)
Dimensions (L×W×H): 2,970 × 1,410 × 1,630 mm
Weight: 2,270 kg
Sound Level (at 7 m): 69 dB
Options
Non‑standard configurations and accessories available on request (filters, control panels, special piping, shipment preparation).
Technical details
- Model: DIS-110VPB
- Rated Pressure: 149 psi / 1.03 MPa
- Air Delivery: 12.2 m³/min (431 cfm)
- Air Tank Capacity: 0.144 m³
- Engine: Isuzu AI-4HK1X
- Fuel: Diesel
- Fuel Consumption: 18.5 L/h
- Tank Capacity: 230 L
- Emission Regulation: Tier 3 (Japanese regulation)
- Dimensions (L×W×H): 2,970 × 1,410 × 1,630 mm
- Weight: 2,270 kg
- Sound Level (at 7 m): 69 dB
