Bronze conveyor roller RR-RP

steelnitrileneoprene®

Description
Finned rollers feature longitudinal grooves on the outer surface and are permanently bonded to a steel insert that provides rigidity and permits customized mounting configurations to suit the application. The grooves reduce surface contact with the workpiece and allow dirt, debris and liquids to pass. Available materials include neoprene, nitrile and urethane with Shore A hardness from 20 to 60.

Available Parts (table)
ID | SKU | Part Number | D in | D1 in | W in | No. of Fins | Durometer Shore A | Material | Color
112219 | RR-9250-2-20-RP | RR-9250-2-20-RP | 2.00 | 1-1/8 | .92 | 3 | 20 | Neoprene | Black
112225 | RR-9250-2-20W-RP | RR-9250-2-20W-RP | 2.00 | 1-1/8 | .92 | 3 | 20 | Nitrile | White
112236 | RR-9250-2-35-RP | RR-9250-2-35-RP | 2.00 | 1-1/8 | .92 | 3 | 35 | Neoprene | Black
112252 | RR-9250-2-35W-RP | RR-9250-2-35W-RP | 2.00 | 1-1/8 | .92 | 3 | 35 | Nitrile | White
112238 | RR-9250-2-35UR-RP | RR-9250-2-35UR-RP | 2.00 | 1-1/8 | .92 | 3 | 35 | Urethane | Yellow
112260 | RR-9250-2-60-RP | RR-9250-2-60-RP | 2.00 | 1-1/8 | .92 | 3 | 60 | Neoprene | Black
112263 | RR-9250-2-60W-RP | RR-9250-2-60W-RP | 2.00 | 1-1/8 | .92 | 3 | 60 | Nitrile | White
112262 | RR-9250-2-60UR-RP | RR-9250-2-60UR-RP | 2.00 | 1-1/8 | .92 | 3 | 60 | Urethane | Blue
112084 | RR-250-2-20-RP | RR-250-2-20-RP | 2.00 | 1-1/8 | 1.94 | 6 | 20 | Neoprene | Black
112093 | RR-250-2-20W-RP | RR-250-2-20W-RP | 2.00 | 1-1/8 | 1.94 | 6 | 20 | Nitrile | White

Product Types

• RR-RP — Finned Rollers, steel insert (1-1/8 in ID)
• RR-R — Finned Rollers, steel insert (1-1/4 in ID)
• RR — Finned Rollers, bronze insert (1/2 in ID)

Technical specifications

• Insert type: steel or bronze (steel insert used for the Roller Only items listed)
• Inner diameter options shown: 1-1/8 inch (page listings)
• Outside diameter (D) examples: 2.00 in (listed parts)
• Width (W) examples: .92 in and 1.94 in (listed parts)
• Number of fins: 3 or 6 (depending on part)
• Materials available: Neoprene, Nitrile, Urethane
• Durometer (Shore A) range: 20 to 60 (parts listed include 20, 35, 60)
• Colors: Black, White, Yellow, Blue (dependent on material/durometer)
