Bronze conveyor roller RR-Rx

steelnitrileneoprene®

Product Description
Solid rollers feature a smooth elastomer surface permanently bonded to a steel insert that provides rigidity and enables customized mounting configurations for industrial applications. Available materials include neoprene, nitrile and urethane with durometer options spanning light to hard (product family 20–95 Shore A). Line drawings shown are not proportional for all parts.

Media

• Roller Material Information (PDF)

Product Types

• RR-Rx (Solid Rollers)
• RR-R (Solid Rollers - Steel insert, 7/8 in ID)
• RR-RP (Solid Rollers - Steel insert, 1-1/8 in ID)
• RR-R (Solid Rollers - Steel insert, 1-1/4 in ID)
• RR (Solid Rollers - Bronze insert, various IDs)

Available Parts (table)
ID | SKU | Part Number | D in | D1 in | W in | Durometer Shore A | Material | Color | PN
110892 | RR-215-20-R | RR-215-20-R | 1.50 | 7/8 | 1.25 | 20 | Neoprene | Black |
110893 | RR-215-20W-R | RR-215-20W-R | 1.50 | 7/8 | 1.25 | 20 | Nitrile | White |
110895 | RR-215-35-R | RR-215-35-R | 1.50 | 7/8 | 1.25 | 35 | Neoprene | Black |
110896 | RR-215-35UR-R | RR-215-35UR-R | 1.50 | 7/8 | 1.25 | 35 | Urethane | Yellow |
110898 | RR-215-35W-R | RR-215-35W-R | 1.50 | 7/8 | 1.25 | 35 | Nitrile | White |
110912 | RR-215-60-R | RR-215-60-R | 1.50 | 7/8 | 1.25 | 60 | Neoprene | Black |
110915 | RR-215-60UR-R | RR-215-60UR-R | 1.50 | 7/8 | 1.25 | 60 | Urethane | Blue |
110917 | RR-215-60W-R | RR-215-60W-R | 1.50 | 7/8 | 1.25 | 60 | Nitrile | White |
110923 | RR-215-80-R | RR-215-80-R | 1.50 | 7/8 | 1.25 | 80 | Neoprene | Black |
110931 | RR-215-80UR-R | RR-215-80UR-R | 1.50 | 7/8 | 1.25 | 80 | Urethane | Red |

Features / Technical specifications

• Construction: Solid elastomer roller permanently bonded to a steel (or bronze) insert for increased rigidity.
• Materials available: Neoprene, Nitrile, Urethane.
• Durometer (Shore A) options: common values shown — 20, 35, 60, 80 (family range 20–95 Shore A).
• Typical dimensions for listed parts: D = 1.50 in, D1 = 7/8 in, W = 1.25 in.
• Color options depend on material (examples: Black = Neoprene, White = Nitrile, Yellow/Blue/Red = Urethane variants).
• Insert options: steel or bronze inserts depending on model/part.
• Insert purpose: provides rigidity and allows custom mounting configurations to suit the application.
• Note: Line drawings are not proportional for all parts.
