RGB optical filter

glassfor camerasindustrial

Overview
Primary color filters for image sensor and MOLED applications. The 5th-generation COLOR MOSAIC™ RGB series is engineered for high-end, high-resolution CMOS and CCD color sensors and MOLED displays.

Product lineup

• RGB 5000 series
• RGB 6000 series
• Low-temperature cure RGB series for OLED

Features & Benefits

• Generation: 5th generation
• Color spectral: Primary color (RGB)
• Pigment control: Very small amount of large-size pigments
• Pixel size: ≥ 1.75 µm
• Exposure dose: 100–400 mJ/cm² (i-line)
• Resistance: Excellent heat and light resistance
• Environment: EHS-approved raw materials
• Packaging: Quart glass bottle, 0.76 L

Technical specifications

• Generation: 5th generation
• Color spectral: Primary color (RGB)
• Pigment control: Very small amount of large-size pigments
• Pixel size: ≥ 1.75 µm
• Exposure dose: 100–400 mJ/cm² (i-line)
• Resistance: Excellent heat and light resistance
• Environment: EHS-approved raw materials
• Packaging: Quart glass bottle, 0.76 L

Typical applications

• Digital cameras, camcorders, security and industrial imaging systems
• High-resolution machine vision and MOLED color filtering
