Visible light optical filter CMY series

yellowcoloredabsorption

Overview
COLOR MOSAIC™ CMY 7000 series complementary color filters are developed for image sensor (IS) applications, optimized for megapixel CMOS and CCD color sensors. They deliver controlled pigment distribution for small-pixel imaging while providing strong heat and light resistance.

Product Lineup

• CMY 7000 series

Features & Benefits

• Application: image sensor applications (CMOS, CCD)
• Generation: 7th generation
• Color spectrum: complementary CMY (cyan, magenta, yellow)
• Pigment control: small amount of large-size pigment to maintain optical consistency
• Pixel size compatibility: ≥1.1 µm
• Recommended exposure dose: 300–1000 mJ/cm² (i-line)
• Resistance: excellent heat and light resistance
• Environment: manufactured with EHS-approved raw materials
• Packaging: 0.76 L quart glass bottle

Technical specifications

• Application: image sensor (IS)
• Series: CMY 7000 series
• Generation: 7th generation
• Color spectral: complementary color (CMY)
• Pigment control: small amount of large-size pigment
• Pixel size: ≥1.1 µm
• Exposure dose: 300–1000 mJ/cm² (i-line)
• Resistance: heat and light resistance
• Packaging: 0.76 L quart glass bottle
