Butterfly valve CAV serieshydraulically-operatedshut-offfor oil
Add to favorites
Compare this product
Characteristics
- Type
- butterfly
- Operation
- hydraulically-operated
- Function
- shut-off
- Media
- for oil
- Body
- screw-in
- DN
Max.: 24 mm
(0.945 in)Min.: 8 mm
(0.315 in)- Pressure
500 bar
(7,251.9 psi)- Temperature
Max.: 80 °C
(176 °F)Min.: -40 °C
(-40 °F)- Flow rate
Max.: 50 l/min
(13.21 us gal/min)Min.: 25 l/min
(6.6 us gal/min)
Description
The valve type CAV, as a slotted throttle, is insensitive to micro contamination.
The valve type CAV can be screwed-in and can be integrated into manifolds. The necessary mounting holes are straightforward to make.
Features and advantages
Various models
Sensitive adjustment and complete shut off possible
Intended applications
General hydraulic systems
Catalogs
Product catalogue
299 Pages
