Power diode P6KE series
TVSaxial-leadbi-directional

power diode
power diode
power diode
Add to favorites
Compare this product


Characteristics

Technology
TVS
Mounting
axial-lead
Function
power
Technical characteristics
bi-directional
DC voltage

Min.: 10.5 V

Max.: 869.4 V

Reverse voltage

Min.: 8.1 V

Max.: 77.8 V

Description

The P6KE Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. Halogen-Free and RoHS compliant Typical maximum temperature coefficient ΔVBR = 0.1% × VBR@25°C Glass passivated junction 600W peak pulse capability at 10×1000μs waveform, repetition rate (duty cycles):0.01% Fast response time: typically less than 1.0ps from 0 Volts to BV min Excellent clamping capability Low incremental surge resistance Typical IR less than 1μA above 13V High temperature soldering guaranteed: 265°C./10 seconds/ 0.375”,(9.5mm) lead length, 51bs., (2.3kg) tension Plastic package has Underwriters Laboratory Flammability classification 94V-O Matte Tin Lead–free plated
