Small food products counting and filling machine RD-SLL-16H

for bottlesfor the food industryfor the pharmaceutical industry

Product Description
Gummy counting and filling line is an automated production line designed to accurately count, fill and seal bottles with gummies for industrial packaging.

Working principle / Process steps

• Bottle unscrambler: arranges loose bottles into a uniform orientation for downstream operations.
• Counting: candies are fed from the feeder into the counting hopper; electronic counters, photoelectric sensors or vision systems count items and dispense them into bottles.
• Desiccant and Capping: a desiccant is placed into the bottle and caps are applied by pressing or screwing.
• Sealing and Labeling: filled bottles move to a sealing unit (foil/aluminum sealing) and then to a labeling machine.
• Inspection and Packaging: finished bottles undergo quality inspection for correct count, sealing and label placement, then are sent to packaging equipment.

How it is used
The counting machine gummy line handles capsules, tablets and gummies into bottles. It is suitable for research institutes, hospitals, pharmaceutical manufacturers, health product producers and packaging lines. The line can integrate with cartoning and labeling machines.

Specification

• Production capacity: 100 bottles/min
• Accuracy rate: > 99.98%
• Delivery: 10 days fast delivery
• Suitable for: 3–40 mm (pectin, sugar-coated, oiled gummies)
• Power: 380/220V 50/60Hz (customizable)
• Total power: 2.5 kW
• Outline dimensions: 1300×1950×1800 mm

Main Features

• Infrared scanning system and FPJ parallel processing technology for high-speed counting.
• Accuracy rate greater than 99.98%.
• Vibrating track fully enclosed to prevent dust ingress and signal short circuits.
• Photoelectric detection with one-to-one control so lanes operate independently.
• Modular design for easy installation, disassembly, maintenance and cleaning.
• Capable of counting various gummies: 3–40 mm (pectin, sugar-coated, oiled).

Main Parts

• Bottle Unscrambler
• Counting / Bottling Machine
• Desiccant Machine
• Capping Machine
• Aluminum Foil Sealing Machine
• Labeling Machine

Technical specifications

• Production capacity: 100 bottles/min
• Applicable products: 3–40 mm pectin, sugar, oiled gummy
• Power: 380/220V 50/60Hz (customizable)
• Total power: 2.5 kW
• Outline dimensions: 1300×1950×1800 mm
• Accuracy rate: > 99.98%
