Gravity bottle unscrambler RD-HSLP-700

pneumaticmechanicalfor the food industry

Overview
High-speed bottle unscrambler HSU-150 automates the sorting and orientation of bulk round plastic bottles ahead of filling, capping and labeling equipment. Bottles are loaded into a hopper, singulated on distribution tracks and aligned using guide slots, push rods, gravity and air jets before transfer to the downstream conveyor.

How it works
The process begins with bulk feeding into the hopper, followed by controlled conveying to distribution tracks. Mechanical and pneumatic devices correct bottle orientation (neck-up or other required position). Singulated bottles are conveyed steadily to the production-line conveyor for filling, capping and packaging.

Short Specifications (summary)

• Capacity: up to 150 bottles/min
• Bottle type: round plastic bottles
• Bottle diameter: 15–200 ml
• Bottle height: 40–180 mm
• Delivery: 7 days (fast delivery)

Technical Table
Production capacity: 60–150 bottles/min
Applicable bottle shape: round bottles
Bottle volume range: 15–200 ml
Bottle height range: 40–180 mm
Power supply: AC 380/220V 50Hz (customizable)

Main Features / Advantages

• Automated sorting and feeding to increase line throughput
• Reduced manual handling and associated labor costs
• Consistent bottle orientation to minimize downstream errors
• Suitable for pharmaceuticals, beverages, food and cosmetics production lines

Main Parts

• Fully enclosed frame
• Engineered 3D layout and drawings
• Low-maintenance access design
• Hopper with lifting/loading feeding system
• Bottle sorting trays and distribution tracks

Specifications (detailed)

• Production capacity: 60–150 bottles/min
• Applicable bottle type: round plastic bottles
• Bottle diameter range: suitable for 15–200 ml
• Bottle height range: 40–180 mm
• Power supply: AC 380/220V 50Hz (customizable)
