Android 14 tablet ST10-A2

10.1"ARM® Cortex®-A55 Quad-coreARM Cortex-A78

Product Overview
The ST10-A2 is a 10.1-inch rugged tablet running Android 14, powered by the MTK MT6877 octa-core processor (2×Cortex-A78 @2.4GHz + 6×Cortex-A55 @2.0GHz). Designed for industrial and outdoor 5G applications, it delivers a 10.1-inch 1200×1920 display, long autonomy with a 10000mAh (38.0Wh) battery, IP68 protection and 1.2m drop resistance. Expandable options include 1D/2D barcode scanner (NLS-N1), multi-system GNSS and an optional stylus. Connectivity includes multi-band 5G, WiFi 6 and Bluetooth 5.2.

Key Features

• Android 14 OS with MTK MT6877 octa-core CPU and Arm Mali-G68 GPU
• 10.1-inch TFT 1200×1920 display, 10-point touch, stylus support
• 8GB RAM / 256GB internal storage (fixed); microSD support via SIM+TF slot option
• 10000mAh (3.8V, 38.0Wh) battery for extended field operation
• Front 5MP and rear 13MP cameras; optional barcode scanner and fingerprint module
• 5G multi-band support, 4G LTE full-band, WiFi 6, Bluetooth 5.2, NFC
• IP68 dust/waterproof rating and 1.2m drop resistance; operating temperature -20°C to 55°C
• Type-C port, dual SIM or SIM+TF slot, physical SOS/Scan button, pogo pins for expansion

Application Scenarios

• Field service and outdoor inspections in harsh environments
• 5G IoT terminals, remote monitoring and data collection
• Warehouse management, logistics and inventory scanning
• Mobile industrial control panels and on-site data entry
• Mapping, GIS, fleet management and asset tracking

Technical Specifications

• OS: Android 14
• CPU: MTK MT6877 Octa Core (2×Cortex-A78 @2.4GHz + 6×Cortex-A55 @2.0GHz)
• GPU: Arm Mali-G68
• Memory: 8GB RAM / 256GB ROM (fixed)
• Display: 10.1-inch TFT, 1200×1920; 350 nits (TYP), 400 nits (MAX)
• Touch: 10-point capacitive touch; stylus support
• Cameras: Front 5MP; Rear 13MP
• Battery: 10000mAh (3.8V, 38.0Wh)
• Connectivity: 5G multi-band (e.g., N1/N3/N77/N78), 4G LTE full-band, WiFi 6 (802.11ax), Bluetooth 5.2, NFC
• GNSS: BDS, GPS, GLONASS, Galileo (optional high-precision module available)
• Audio: Built-in microphone and speaker
• Ports & Slots: Type-C ×1; SIM ×2 or SIM+TF slot; pogo pins for USB/serial expansion
• Durability: IP68 dust/waterproof; 1.2m drop resistance
• Temperature Range: Storage -40°C to 60°C; Operation -20°C to 55°C
• Size & Weight: 250×166×14.2mm; 800±50g
• Optional Modules: 1D/2D barcode scanner (NLS-N1), fingerprint, UHF module, high-precision GNSS
