Heavy duty mounting bracket IM100.T

The IM100.T Series Mount is an industrial grade kinematic optic mount designed for exceptional performance and flexibility in photonics and laboratory applications. It features precision 100TPI adjustment screws, providing excellent resolution and tactile feedback. The solid 3/8-inch thick aluminum back plate is engineered with two 8-32 [M4] mounting options, allowing for both right or left-hand compatibility.

Product Features

• 100 pitch lockable adjustment screws
• Color coded axis knobs
• Available in Tip/Tilt or Tip/Tilt/Translate versions
• Vacuum compatible versions available upon request

Performance Specifications

• Travel per axis: 8 degrees
• Minimum controllable motion: 3.8 arc seconds

Characteristics / Technical Specifications

• Series: IM100.T
• Adjustment screws: 100TPI, lockable
• Mounting: Two 8-32 [M4] options, right or left-hand
• Back plate: 3/8-inch thick aluminum
• Axes of adjustment: Tip/Tilt or Tip/Tilt/Translate
• Color coded axis knobs
• Vacuum compatibility: Available upon request
• Travel per axis: 8 degrees
• Minimum controllable motion: 3.8 arc seconds
