3-axis CNC machining center FH550SX
horizontalCAT5060 tools

3-axis CNC machining center - FH550SX - Toyoda Machine Works - horizontal / CAT50 / 60 tools
3-axis CNC machining center - FH550SX - Toyoda Machine Works - horizontal / CAT50 / 60 tools
3-axis CNC machining center - FH550SX - Toyoda Machine Works - horizontal / CAT50 / 60 tools - image - 2
3-axis CNC machining center - FH550SX - Toyoda Machine Works - horizontal / CAT50 / 60 tools - image - 3
3-axis CNC machining center - FH550SX - Toyoda Machine Works - horizontal / CAT50 / 60 tools - image - 4
Add to favorites
Compare this product

Characteristics

Number of axes
3-axis
Spindle orientation
horizontal
Spindle mount
CAT50
Number of tool stations
60 tools
Other characteristics
high-speed, high-performance, high-rigidity, high-precision
X travel

750 mm
(29.53 in)

Y travel

800 mm
(31.5 in)

Z travel

850 mm
(33.46 in)

Rotational speed

15,000 rpm
(94,248 rad.min-1)

Power

50 ch
(50 hp)

Workpiece max height

1,000 mm
(39 in)

Table load capacity

800 kg
(1,764 lb)

Weight

16,100 kg
(35,494.42 lb)

Overall length

3,312 mm
(130.4 in)

Overall width

5,695 mm
(224.2 in)

Overall height

3,200 mm
(126 in)

Description

The FH550SX is a powerful, high-speed horizontal machining center featuring an 8,000 RPM high-torque spindle, with an option of 15,000 RPM spindle, and a rapid feedrate of 2,362 ipm (60 m/min). This machine has dual ballscrew drive on the Y and Z axes, and a Meehanite cast iron base for improved rigidity.
