Multitouch screen monitor W43L100-PCA1OD

multi-touch screenprojected capacitive touchscreenPCAP touchscreen

Overview
The W43L100-PCA1OD is a 43-inch industrial outdoor chassis display with projected capacitive (PCAP) multi-touch. It delivers a sunlight-readable high-brightness panel and supports VESA mounting and a range of environmental options for continuous 24/7 operation in industrial and commercial outdoor settings.

Key Features

• Sunlight readable high-brightness solution (1500 nits)
• Supports VESA mount and universal wall/flat surface installation
• Projected capacitive (PCAP) multi-touch
• Operating temperature: -10°C to 60°C (standard)
• Optional heater for extended operating range: -25°C to 60°C
• Optional solar radiation protection with UV film for direct-sun environments

Certifications

• CE
• FCC

I/O and Accessories

• USB: 1 x USB (for touch)
• Video: 1 x VGA, 1 x HDMI, 1 x DVI (optional)
• Standard accessories: 1 x VGA cable; 1 x HDMI cable; 100~240V AC to DC adapter; power cord; manual; VESA screws (varies by product)
• Optional accessory: remote controller (varies by product)

Usage & Mounting
Supports VESA mounting and universal wall/flat surface installation for easy integration in kiosks, outdoor signage and industrial installations. Metal housing with aluminum bezel and fanless design provide durable operation in continuous-use environments.

Technical specifications

• Model: W43L100-PCA1OD
• Touch / Glass: Projected Capacitive Multi Touch Screen
• Size: 42.5 inches
• Resolution: 1920 x 1080
• Panel Brightness: 1500 nits
• Contrast Ratio: 4000:1
• View Angles: 89, 89, 89, 89
• Display Color: 16.7M Colors
• Active Area: 940.896 x 529.254 mm
• Operating Humidity: 10% to 90% RH, non-condensing
• Operating Temperature: -10°C to 60°C (optional -25°C to 60°C with heater)
• Storage Temperature: -20°C to 70°C
• IP Rating: Front IP65
• Dimensions: 1028.8 x 617 x 48 mm
• Mounting: VESA mount
• Enclosure: Metal housing with aluminum bezel
• Cooling System: Fanless design
• Power Rating: 24V DC in
• Buttons: 5 keys (-, +, Power, Esc, Enter)
