1、The renowned brand engine equipped features strong power, ultra-low emission, and higher fuel efficiency.
2、Compact structure, low turning radius, and strong site adaptability.
3、The international interchangeable quick-change coupling enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.
4、The ROPS&FOPS cab and the seat belt, bumper, fire extinguisher, and safety hammer equipped guarantee the personal safety of the operator.
5、The cab can be tilted backward for a large angle to make the repair and maintenance portions more accessible.
Rated load: 750kg
Operating weight: 3140kg
Maximum breakout force: 18kN
Rated power: 49.3/36.8Hp/kw
Rated speed: 2500rpm
Maximum speed: 14Km/h
Hydraulic flow rate: 62.5L/min
Maximum operating height: 3878mm
Bucket hinge pin height: 3057mm
Cabin top height: 1960mm
Maximum horizontal height of bucket bottom: 2851mm
Maximum unloading height: 2375mm
Unloading distance: 575mm
Wheel base: 1027mm
Wheel track: 1380mm
Tire edge width: 1640mm
Bucket edge width: 1800mm
Bucket capacity (stacking height): 0.45m³
Bucket capacity (tiling): 0.35m³
