STL's 26 Bit High Resolution Multi Channel Professional data acquisition System /
High Resolution Digital System Voltmeter is designed for uncompromising signal readout of various sensors in Production, Quality Control, Field Applications or Lab.
The combination of the linearity and stability of a calibration instrument with the system functionality of up to 3000 simultaneously measured channels is unique in the measurement industry.
Highlights :
• 26 Bit data acquisition
• low noise, large dynamic, high linearity
• Multi channel design for up to 3000 channels
via Ethernet
• Fast and highly accurate, 8.5 digits, DC- 10 KHz
• Ultra stable
• Qualified for calibration and certification
• Remote Testing capability via Intranet or Internet
The system is the appropriate answer for higher speed and accuracy in production testing and quality assurance as required in high throughput production, R&D, and also for all kind of high end calibration requirements.
+++ STL is searching worldwide for dealers +++ |
|
Advanced Diagnostics in a Portable, Expandable Package
Not all data collection systems are created equal. With thousands of users around the globe, ADRE PDS's are trusted by machinery professionals in a wide variety of industries for their most advanced diagnostics requirements. ADRE truly is the diagnostic product that customers across industries trust for their diagnostic and data collection needs.
Synonymous with quality and advanced technology, ADRE leads the way.
|
|
RogaDAQ 16 datalogger Description:
With the introduction of the RogaDAQ16 USB2.0 manufacturers of data acquisition system, a new age of measurement technology begins.
USB 2.0 / 480MBIT (USB1.1/12MBIT COMPATIBLE)
16 analog input channels (16bit/500kHz max.)
IEPE sensor supply (24V/4mA)
0.125V to 10V input range
Individual preamplifiers
4 analog output channels (16bit/100kHz)
Powerful INDUSTRIAL DSP (255MIPS) for filtering, control etc.
24 digital I/Os
Optional 24bit professional counter, timer, PWM, incremental encoder
Free drivers for major application software
including DASYLab; LabView & DiaDem drivers & RogaRec Software; FlexPro7 Standard
The RogaDAQ16 is an affordable multichannel IEPE solution. The USB 2.0 interface permits unrivalled portability. Hotplugging the data data logger during operation has now become a reality. The compact and rugged measurement unit with its BNC suppliers of connectors breakout boxes obsolete. Downward compatibility to USB 1.1 also permits to run this high performance measuring system with older hardware. Simplicity of integration, whether mobile or stationary, has reached a new level.
|
|
VibDAQ; Manufacturers of data acquisition Module with ICP® or voltage inputs,
multifunctional data acquisition module in a portable housing.
RogaREC included.
Datalogger with ICP® (IEPE) or voltage inputs.
The VIBDAQ-4+,8+,16+ series offers high-speed, multifunctional data acquisition module in a portable housing. Vibdaq is fully operated by USB 2.0.
Modules offer synchronous sampling for all channels (0 degree phase shift), inputs can be set in ICP® or voltage mode.
|
|
FieldLogger - Virtual Professional recorder
This microprocessor based suppliers of data acquisition and recorder can handle any analog input and will operate as an RTU linked to a PC for on line recording and supervision or as a stand alone data logger with real time clock and graph capabilities. DIN rail compatible, it has 8 universal channels that will accept different input sensors at the same time and can be easily expanded.
8 universal analog channels per module.
Accepts t/c J, K, T, E, N, R, S, B; 4-20 mA, Pt100, 0-50 mV without hardware change.
Internal memory (optional) for 32,000 to 128,000 recordings and real time clock.
Input resolution: 12,000 levels.
Accuracy: 0.1 % of full scale.
Scanning: 8 channels in 0.5 seconds.
Reading rate: from 0.2s to 1 day.
Power: 100-240 Vac, optional 24 Vdc/ac
Alarms: 2 relays 3 A for the 8 channels.
Digital input for remote START/STOP.
RS-485, MODBUS - RTU, 19200 bps.
35 mm DIN rail mounting.
ABS enclosure: 105 x 90 x 60 mm
|
|
TagTemp is a compact water proof temperature data logger. Housed in an IP67 enclosure, TagTemp can be installed in harsh environments in different applications.
It can be easily programmed and set via a handy infrared IR-LINK 3 interface connected to a USB port under Windows software or with a Palm compatible PDA IrDA interface under PalmOS. LogChart II software allows for logger configuration, recorded data retrieval, plotting, historical analysis and exports data to spreadsheets.
Powered by an inexpensive lithium coin cell, it can operate continuously for more than one year. Its high resolution (14 bit ADC) and data memory capacity (16k loggings) makes it the ideal product for accurate monitoring of temperature for long periods or fast sampling. |
|
With more than 100,000 MGCplus channels in different applications worldwide, HBM's MGCplus system has achieved acceptance as a measurement standard. The wide spectrum of supported transducers, fieldbus connections and standard PC interfaces are some of the features which indicate that it is a truly integrated measurement device.
The MGCplus is today the suppliers of data acquisition (DAQ) system of choice for almost all industrial, laboratory and R&D measurement applications in:
Test rigs
Calibration
Manufacturing
Weighing
Experimental stress analysis
Mobile data acquisition.
Main features and benefits:
Modular, computer-controllable professional amplifier system
Self-supporting plug-in amplifier units available for all common measurement quantities, e.g. SG transducers, inductive transducers, DC voltages, manufacturer of thermocouples, torque detection
Various computer interfaces (RS232, RS485 and IEEE488), also available with standard protocols such as 3964R, ModBus and Ethernet
Parallel, synchronised data acquisition from max. 16 channels per device, 10,000 samples per sec/channel
Operation possible via control panel display or PC in conjunction with relevant software. |
|
| Parr Instrument Company's 4846 Supplier of data acquisition System is a PC based data logger system designed for users of Parr's 4840 Series Controller, which incorporates modules providing analog outputs of temperature, pressure and stirring speed. It can accommodate up to 8 analog inputs. (0-5 VDC only) and uses a 12-bit A/D professional converter. |
|
Automatically creates test certificates, A4-format
Test graph on your own PC or laptop
Up to 4 input channels for pressure or temperature
Suitable for all types of pressure test units
Calibrated system, ready-for-use
User-friendly professional software including manual on CD ROM
|
|
The DT9841 is a real-time USB Industrial data acquisition Module with an embedded INDUSTRIAL DSP for high-accuracy sound and vibration testers. It features full data acquisition capability: eight 24-bit analog inputs, two 24-bit analog outputs, 24 lines of digital I/O, and three 32-bit professional counter timers.
Key Features:
* Delta-Sigma A/D and D/A converters for high-accuracy measurements at up to 800 kS/s (aggregate)
* Real-time control with embedded TMS320C6713, 300 MHz DSP for stand-alone or system operation
* Software programmable DSP
* Two packaging configurations: Sleek Box version for easy connections or board-level version for OEM-embedded applications
* Flexible memory configuration: 128 MB SDRAM and 2 MB Flash for autonomous operation
* Scalable design for connecting up to 8 modules for high-channel count applications
* High-speed host USB 2.0 host interface (480 Mbits/seconds)
* 500 V Isolation for maximizing signal integrity |
|
DaqBoard/1000 Series
16-Bit, 200-kHz PCI Data acquisition DaqBoards
The DaqBoard/1000 Series of low-cost, multifunction PCI boards are ideal for OEM or embedded applications. These boards are best suited to applications with pre-conditioned voltage signals up to 16-channels. For applications that require channel expansion or signal conditioning for measuring temperature, strain, vibration and more, consider our DaqBoard/2000 Series with its line of over 40 DBK signal conditioning and expansion options.
Key Highlights
• 16-bit, 200-kHz A/D industrial converter
• 8 differential or 16 single-ended analog inputs (professional software selectable per channel)
• Up to four boards can be installed into one PC
• 100% digital calibration
• 512 location channel/gain FIFO
• DMA bus mastering for synchronous analog I/O, digital I/O, and professional counter inputs
• Trigger modes include digital and software, with <5 µs latency
• Virtually infinite pre-trigger buffer
• Two 16-bit, 100-kHz analog outputs with infinite continuous waveform output capability
(model /1000 only)
• 24 digital I/O lines, can be scanned synchronously or asynchronously with analog
and frequency inputs
• Four counter/pulse input channels can be scanned synchronously or asynchronously
with analog and digital inputs
• Two timer/pulse output channels |
|
LDS Nicolet provides a complete family of suppliers of data acquisition systems designed to provide continuous data recording to disk at high aggregate speeds. Choose from a range of systems offering high-precision transient data capture, data recording or both. LDS-Nicolet's data acquisition systems and transient recorders have a history of unparalleled performance.
|
|
National Instruments, a market leader in PC-based supplier of data acquisition, offers the most complete family of data acquisition devices for desktop, portable, and networked applications on several buses, including PCI, PCI Express, PXI, PCMCIA, USB, CompactFlash, Ethernet, and FireWire, and many operating systems, including Windows, Linux, Mac OS X, Pocket PC/Windows CE, and RTX.
|
|
Both the model 3310 and 3320 G-Loggers come complete with an RS-232 interface cable and the G-Logger Professional software Program which allows you to set up the G-Logger for a particular professional data acquisition mission, acquire your data,
and then transfer the resulting data to your in 95/98/NT4.0/2000 PC. No data acquisition card is needed because all the communication is handled via the RS-232 COM port on your PC. The G-Logger Software program is meant to be used in conjunction with a plotting program. Should you already own or choose to provide your own plotting software, the G-Logger Software Program can be set to output the data in ASCII comma delimited format which is readable by most any data graphing software
package.
The model 3310 is a standalone unit. The Model 3320 G-Logger is designed to be used with either one model 2420 triaxial accelerometer or up to 3 Model 2010 single axis accelerometers. In order to connect 1, 2 or 3 model 2010
accelerometers, a Model 3901 (tri-Y) Adapter Cable is also needed. This adaptor allows the 2010's to be separated by up to 6' from each other. A 10' extension cable is also included and can be inserted between the model 3320 G-Logger and the model 3901 (with 2010's connected to it) or between the model 3320 G-Logger and a model 2420 Triax.
|
|
Galaxie professional software is comprehensive chromatographic data handling software for both standalone and client professional server application.
Galaxie software provides:
• A choice of client server or standalone configurations and control of instruments from multiple vendors.
• Chromatographic data acquisition suppliers, peak processing and calculations
• Automation
• Regulatory Compliance
• Custom calculation using Galaxie variables
Galaxie has a series of plug ins and industry driven tools which provide custom calculations and advanced automation including: advanced multi-instrument/LIMS automation, calculations for flavors and fragrances, automated methods development and method validation, database storage and retrieval of chromatographic files and petrochemical calculations.
Galaxie software serves the needs of pharmaceutical, petrochemical and environmental industries
|
|
The MSX-Box (Measurement Solution eXtended) is a realtime embedded system for networked control, regulation and acquisition of measurement data. Equipped with standard components like PCI backplane, PCI I/O board, CPU etc. the MSX-Box works without wearing parts like hard disk, drive, professional keyboard, mouse etc. It saves place and therefore can be integrated easily into small 19" racks or mounted on a rail.
In the MSX-Box also further PCI measurement boards that are available on the market can be integrated.
Via Ethernet (TCP/IP) or RS232 interfaces measurement data can be exchanged with other systems. An IP-address can be specified for the system. Furthermore, the MSX-Box supports server functions so that the system status or current processes of remote professional computers can be called.
Further interfaces are optionally available:
1 x RS232 or 1 x RS485 optically isolated as well as a field bus interface and 1 x profibus slave or rather 2 x interbus and up to 8 CAN interfaces.
The CPU (MIPS 64 bit processor), developed by Addi-Data, was chosen with the intention to grant a long-term availability of the PCI-I/O boards and herewith the durability of the applications.
|
|
| Manufacturer of data acquisition is a completely redesigned data acquisition system combining GE's hardware capability with the new Sxp professional software platform. The new system consists of the 408 Dynamic Signal Processing instrument (DSPi) and ADRE® Sxp software. Highly portable, ADRE® Sxp is designed to meet the changing needs of various fleet asset management programs as well as all other industries where speed and flexibility in data collection are a must. ADRE® Sxp can operate stand-alone in test stands, and with its remote viewing and operating capabilities, offers users large potential savings on unnecessary travel expenses. |
|
| Agilent Technologies has provided suppliers of data acquisition solutions for more than twenty-five years. Today we provide solutions for electrical, physical, mechanical, and acoustic applications. Our data acquisition solutions are based on industry standard professional software and modular hardware that can meet your current and future needs. |
|
The DT9832 is a family of high speed, high performance USB Industrial data acquisition Modules that provide simultaneous analog input operation at up to 2.0 MHz per channel. Each analog input has its own A/D professional converter to eliminate phase shift between channels and to allow you to correlate measurements at the exact same instant in time. Additionally, all functions of the module (A/D, D/A, DIO, C/T, Q/D) can be triggered simultaneously and the data streamed synchronously to host memory. These USB DAQ modules also feature 3 quadrature decoders for measuring absolute and relative position and for detecting rotational speed.
Key Features:
* Simultaneous A/D operation with sampling rates up to 2.0 MHz per channel
* All subsystems operate synchronously at 48 MHz.
* 2 or 4 analog inputs, 2 waveform analog outputs, 16 digital inputs, 16 digital outputs, 2 32-bit industrial counter timers, and 3 quadrature decoders.
* 16-bit deglitched DAC’s run at 500 kS/s per channel for waveform generation.
* 500 V isolation provides low-noise measurements and protects PC.
* Ships with DT-Open Layers device drives, Ready-to- measure applications, Measure Foundry evaluation, and much more. |
|
Analog I/O
12-bit or less resolution
14 and 16 bit resolution
Temperature
Analog Output
High-drive Voltage
Voltage/Current
Voltage
Digital I/O
High Voltage
Parallel
Counter-Timer |
|
Measurement Professional computing today announced the release of three new 1-MHz, 16-bit multifunction USB suppliers of data acquisition devices, and a cost-saving expansion module for high channel count applications. The USB-1616HS, the USB-1616HS-2, and the USB-1616HS-4 deliver outstanding performance with synchronous analog, digital, and frequency I/O in one compact package. The AI-EXP48 plug-in expansion module coupled with any of the USB-1616HS series modules can quadruple the analog input channel count.
The USB-1616HS series modules have a unique, low-latency control output mode, whereby any input—analog, digital, or industrial counter, can control an output—digital, analog, or timer, based on pre-defined limits, including hysteresis. The outputs are controlled directly from the USB-1616HS series module, and do not require PC intervention. This results in response times that are measured in microseconds instead of milliseconds
The USB-1616HS series offers extensive trigger options, ranging from analog trigger with 1 µs max latency, to multichannel triggering, where any combination of analog, digital, and counter input channels can be combined to initiate the trigger. Other trigger modes include digital pattern, level, edge, inside/outside window, and pre- and post-trigger.
|
|
Accurate conversion of physical parameters, such as temperature, pressure, and strain, into digital data is a challenging task.
VXI Technology combines superior accuracy, high-density, and modularity specifically targeting these applications.
Essential features such as integrated signal conditioning, internal self-calibration, open signal path detection, and flexible open standard programming interfaces are standard. |
|
| The E-PDISO16 has one built-in 10/100 BASE-T auto-negotiation, high-speed communication port. With the Ethernet interface, you can remotely access and configure your E-PDISO16 from anywhere on the network. Only one computer can control the E-PDISO16 at one time. The networking protocol is TCP/IP. You can send your data over 100 meters at data speeds of up to 100 Mbps using only one Ethernet cable connected to your computer. |
|
Personal Daq/3000 Series
1-MHz, 16-Bit USB Multifunction Modules
– Models /3000, /3001, /3005
The new USB 2.0 Personal Daq/3000 series offers high speed, multifunction professional data acquisition in a low-cost, portable package. The module offers synchronous and concurrent voltage input, temperature input, waveform output, industrial counter input, quadrature industrial encoder input, timer output, and digital I/O.
Key Highlights
• 1-MHz, 16-bit multifunction USB modules
• Synchronous analog input, analog output,
digital I/O, and counter/timer I/O
• 8 differential or 16 single-ended analog inputs (professional software selectable per channel)
• Manufacturers of thermocouple inputs on any of the 8 differential inputs
• User-expandable up to 64SE/32DE analog inputs including thermocouple measurements
• Up to four 16-bit, 1-MHz analog outputs
• 24 high-speed digital I/O lines
• Four 32-bit counter input channels with quadrature encoder capability
• Low-latency control output capability
(as low as 2 µs latency) |
|
|
|
