Two-station skiver CSM05

continuousfor abrasive clothfor abrasive paper

The skiving machine type CSM05 is manufactured to process simultaneously both laps of paper and cloth wide belts with maximum joint length of 2000 mm (special execution for segmented belts up to 3400 mm). The CSM05 is indicated for converters with high productions. Technical Data - Automatic continuous cycle with a feeding conveyor belts system, at variable speed - Ideal either for overlapped joints or butt joints - Cycle with variable speed up to 12 m/min. (367 FPM) - Standard working direction from left to right - In the standard version, the machine can be provided with a maximum of 15 working units and 2 gluers (roller NGA-15 or spray NSA), 8 working units on the upper working line and 7 on the lower one - Infrared oven, 3000 mm length, with stepless regulation, installed after the gluing unit - Inserting station for 2000 mm wide belts. 3400 mm is also possible, for segmented belts processing - Motorized carpet to guide the belt out of the skiving machine Size and Power (with Joining Station) - Overall machine dimensions: 18.9 x 4.4 x 2.5 m - Approx. weight: 9,600 kg - Installed power: 58 kW - Air consumption: 17,000 Nl/h (air blows included), 7,000 Nl/h (without air blows)
