Two-station skiver CSM02

continuousfor abrasive clothfor abrasive paper

The skiving machine type CSM02 is manufactured to process simultaneously both laps of paper and cloth narrow belts. Even though ideal for narrow belts, the machine can be equipped to work also wide belts. The CSM02 machine is indicated for converters with high productions. Technical Data - Automatic continuous cycle with a feeding conveyor belts system, at variable speed - Ideal either for overlapped joints or butt joints - Cycle with variable speed up to 12 m/min. (367 FPM) - Standard working direction from left to right - In the standard version, the machine can be provided with a maximum of 12 working units and 2 gluers (roller NGA-15 or spray NSA), 7 working units on the upper working line and 7 on the lower one - Infrared oven, 2400 mm length, with stepless regulation, installed after the gluing unit - Inserting station for 1500 mm wide belts - Nylon roller table as support for long and for wide belts on hinges to be swinged up or down Size and Power (with Joining Station) - Overall machine dimensions: 12.5 x 1.3 x 2.3 m - Approx. weight: 6,100 kg - Installed power: 32 kW - Air consumption: 17,000 Nl/h (with air blows), 7,000 Nl/h (without air blows)
