Paper baling press HBA series

for textilesfor cardboardhorizontal

Product Overview
The Enerpat HBA Series horizontal hydraulic baler is engineered for baling mattress fabrics, foam, textiles and cardboard to optimize material density for transport and storage. Large feed hoppers accept gravity feed or belt-conveyor automatic feeding. The series supports a range of bale sizes and press forces to match different recycling and baling lines and is used in global recycling and industrial applications.

Features

• Automation for efficient continuous operation
• Auto tie (German auto-tying system) for consistent, secure bale tying
• Three-direction bale closing mechanism for controlled bale shape
• Three-direction compression using triple hydraulic cylinders for uniform compaction
• Cartridge-style hydraulic valve group for high flow and fast response
• H-type tapered hydraulic fittings to minimize leakage risk
• UK Hallite hydraulic seals for extended service life
• Premium components selected for industrial reliability
• High-strength quenched steel wire — wear- and corrosion-resistant
• Siemens / Schneider PLC system for programmable control
• Touchscreen and button one-click operation with automatic alarm
• Smart programming to set compression and feeding cycles; real-time monitoring of runtime, current and temperature
• Modular plug-and-play design; bale chamber depth can be optimized per customer requirement

Product Applications

• Recycling mattress fabric, mattress foam and mattress textiles
• Cardboard baling and other horizontal baling tasks (waste paper, corrugated, mixed textiles)

Model Specifications (table)
Model | Bale Size (WxHxL)(mm) | Bale Weight (Cardboard)(kg) | Motor Power (kW) | Press Force (t) | Machine Size (LxWxH)(mm)
HBA-30-5050 | 500×500×L | 40-70 | 11 | 30 | 5300×2600×1750
HBA-40-7272 | 720×720×L | 200-500 | 22 | 40 | 6770×3050×3580
HBA-60-11075 | 1100×750×L | 400-700 | 22 | 60 | 6880×3850×3550
HBA-80-11075 | 1100×750×L | 600-900 | 37 | 80 | 6880×3850×3550
HBA-100-110110 | 1100×1100×L | 800-1100 | 45 | 100 | 8560×3950×4550
HBA-120-110125 | 1100×1250×L | 900-1200 | 55 | 120 | 9250×4150×4850
HBA-150-110125 | 1100×1250×L | 1100-1300 | 90 | 150 | 10050×4100×4910
HBA-200-110125 | 1100×1250×L | 1250-1350 | 110 | 200 | 10050×4100×4910

Technical Specifications

• Customization: Available (Customized)
• Condition: New
• After-sales Service: Overseas Service Center Available
• Press Force: 30t - 200t (varies by model)
• Motor: 11 kW - 110 kW (model dependent)
• Tie Model: Auto Tie
• Baling Type: Horizontal Baling
• Transport Package: Plastic Film, Steel Frames, and Wooden Boxes
• Trademark: Enerpat
• Origin: China
• HS Code: 8422400090
• Production Capacity: 20 PCS / Month
• Price Range: US$14,000.00 - US$200,000.00 per Set (MOQ: 1 Set)
• Multiple models available (8 models shown)
