Side-mount electrical cabinet air conditioner Model HT4215

compactfor computer roomsindustrial

Overview
High-temperature NEMA 12 (IP54) Cabinet Cooler Systems by EXAIR for continuous operation in ambient temperatures from 125°F to 200°F (52°C to 93°C). Systems use a vortex tube to produce cold air from compressed air with no moving parts. Continuous-operation models include a 5-micron water‑and‑dirt filter separator and a cold air distribution kit for targeted cooling and enclosure purge.

Applications

• Programmable controllers (PLCs)
• Line control cabinets
• Motor control centers
• Relay panels
• NC/CNC systems
• Modular control centers
• CCTV camera housings
• Computer and electronics cabinets
• Laser housing cooling
• Industrial electronic scales

Advantages

• Rated for ambient temperatures up to 200°F (93°C)
• Low acquisition and lifecycle cost
• Compact, panel-mounted installation through standard knockout
• Cooling capacities up to 5,600 Btu/hr (1,641 W)
• Quiet operation; sound can be reduced with optional muffler
• Preserves NEMA 12 integrity (IP54) and prevents ingress of dust and oil
• Creates slight positive pressure to purge contaminants
• No CFCs and no internal fans or filters required
• No moving parts — minimal maintenance
• Reduces nuisance trips and heat-related failures

Models (NEMA 12 High Temperature Cabinet Cooler Systems, Continuous Operation)
HT4215 | 1,000 Btu/hr (293 W)
HT4225 | 1,700 Btu/hr (498 W)
HT4230 | 2,000 Btu/hr (586 W)
HT4240 | 2,800 Btu/hr (821 W)
HT4250 | 3,400 Btu/hr (997 W)
HT4260 | 4,000 Btu/hr (1,171 W)
HT4270 | 4,800 Btu/hr (1,406 W)
HT4280 | 5,600 Btu/hr (1,641 W)

Performance (Capacity & Sound Level at 100 PSIG)
Cooling capacities shown at 100 PSIG (6.9 BAR) supply pressure. Sound levels measured at 1 m with optional cold muffler installed where noted.

• HT4215 — 1,000 Btu/hr (293 W) — 73 dBA*
• HT4225 — 1,700 Btu/hr (498 W) — 74 dBA*
• HT4230 — 2,000 Btu/hr (586 W) — 74 dBA*
• HT4240 — 2,800 Btu/hr (821 W) — 78 dBA*
• HT4250 — 3,400 Btu/hr (997 W) — 75 dBA*
• HT4260 — 4,000 Btu/hr (1,171 W) — 77 dBA*
• HT4270 — 4,800 Btu/hr (1,406 W) — 77 dBA*
• HT4280 — 5,600 Btu/hr (1,641 W) — 79 dBA*

How it works
Compressed air enters the vortex-tube-powered Cabinet Cooler and splits into hot and cold streams. Hot air is exhausted and muffled; cold air is discharged into the enclosure via the cold air distribution kit. The device maintains slight positive pressure to purge contaminants and prevent ingress of outside air.

Other considerations

• Filtration: Continuous systems include a 5 µm automatic‑drain water‑and‑dirt filter separator. If oil is present, add a coalescing/oil‑removal filter.
• Cold Air Distribution Kit: Flexible tubing, connectors and clips direct cold air to the enclosure interior or specific hot spots.
• Humidity: Continuous units stabilize enclosure relative humidity at ~45% when sealed, preventing condensation.
• Inlet Air Temperature: Expect ~54°F (30°C) temperature drop from supply air at 100 PSIG; higher inlet temperatures or lower pressure reduce capacity.
• Mounting: NEMA 12 (IP54) units mount through standard knockouts on top or side; side‑mount kits available for limited-top-space installations.
• Controls: Continuous models include filter and distribution kit. Thermostatic and ETC (Electronic Temperature Control) models (separate SKUs) include solenoid valves and digital temperature control.
• Safety & Compliance: All units are UL Listed and CE compliant.

Technical specifications

• Brand: EXAIR
• Series: NEMA 12 HT Cabinet Cooler® Systems (Continuous Operation)
• Ambient temperature rating: 125°F to 200°F (52°C to 93°C)
• Cooling capacity range: 1,000 to 5,600 Btu/hr (293 to 1,641 W)
• Typical temperature drop from supply air: ~54°F (30°C) at 100 PSIG (6.9 BAR)
• Construction: Materials vary by model; NEMA 12 units protect against dust and oil (IP54)
• Includes (continuous models): 5 µm water‑and‑dirt filter separator and cold air distribution kit
• No moving parts (vortex tube technology)
• UL Listed and CE compliant
• Model/sku shown on page: PHT4208 (configurable product variations available)
• Cooling capacities at 100 PSIG; sound levels vary by model and can be reduced with optional cold muffler
