Die sinking electrical discharge machine ED3000-2H CE

wire EDMCNC

Product Overview
The ED3000-2H CE is a die-sinking EDM designed for heavy mould and die machining, offering extended X/Y travel and a large worktable for processing oversized workpieces. X/Y travel reported in header: 2550(1275) x 1000 mm. Z travel: 600 mm. Work table: 3100 x 1100 mm. Max. work piece (header): 3700 x 1650 x 750 mm.

Specification
The page specification block provides the following technical dimensions and capacities:
X/Y travel: 2550(1275) x 1000 mm
Z travel: 600 mm
Work table: 3100 x 1100 mm
Max. work piece size: 3700 x 1650 x 750 mm
Max. work piece weight: 16000 kg
Max. electrode weight: 500 kg
Machine weight: 21000 kg
Outside dimensions (Machine body + Travel + Tank + Generator): 6500 x 4610 x 3700 mm
Electrode Head to Work Table Distance: 760 ~ 1360 mm

Features

• Superior erosion control using a MOSFET-based sparking circuit to reduce electrode wear and maintain high erosion speed with smooth surface finish.
• Modular front/back generator assembly for simplified maintenance and quick PCB/service access.
• Double heat-flow separation isolates hot components from cold circuits to improve generator stability and minimize upkeep.
• After-sales support including operator training, maintenance guidance and application assistance to support production uptime.

Generator / Functional Highlights

• MOSFET-based sparking circuit for reduced electrode wear and faster erosion.
• Front/back assembly modular design for easy maintenance and service.
• Double heat flow separation to stabilize generator operation and reduce maintenance needs.

OB-Mode (Illustrations)
The product page includes multiple OB-mode photographs and illustrations showing operation, observations and generator internals (image gallery on the page).

Accessory
Standard Accessories

• Alcohol extinguisher
• Working lamp
• Leveling pad
• Flushing unit
• Paper filter
• 1/2 drill chuck
• Tools box
• Clamp jig

Options

• Oil cooling system
• Permanent magnetic pedestal
• Tungsten carbide sparking circuit

Technical specifications

• Model: ED3000-2H CE
• X/Y travel: 2550(1275) x 1000 mm
• Z travel: 600 mm
• Work table size: 3100 x 1100 mm
• Maximum work piece size: 3700 x 1650 x 750 mm
• Maximum work piece weight: 16000 kg
• Maximum electrode weight: 500 kg
• Machine weight: 21000 kg
• Outside dimensions (machine body + travel + tank + generator): 6500 x 4610 x 3700 mm
• Electrode head to work table distance: 760 ~ 1360 mm
