Manually switched magnetic lifter FX-R100

handlingrectangular

Product name
FX-R100 Permanent lever lifting magnet for round material, capacity 100 kg

Overview
The FX-R100 magnetic lifter is a manual, lever-activated permanent magnetic solution for safe handling of ferrous round components in storage, transport and during machine loading/unloading. Its optimised polar surface and compact design enable secure engagement across a range of diameters.

Designed for round material
An advanced multi-pole magnetic system concentrates the magnetic field on an optimised polar surface to ensure reliable grip on rings, shafts and cylindrical parts. The unit is activated and released by a single robust sliding lever for straightforward operation.

Origin and compliance
Manufactured in Germany. Conforms to CE / EN 13155 / MRL 2006/42 EWG.

Documentation
Drawing available: SERIE-FX-R (PDF)

Applications

• Lifting and handling ferrous round loads in storage
• Transport of round components
• Loading and unloading components from machines

Technical specifications

• Model: FX-R100
• Maximum capacity: 100 kg
• Intended use: round material (rings, shafts, cylindrical parts)
• Magnetic system: advanced multi-pole with optimised polar surface
• Activation: single robust sliding lever
• Suitable for: storage, transport and machine loading/unloading
• Manufacturing origin: Germany
• Standards/compliance: CE / EN 13155 / MRL 2006/42 EWG
