Manually switched magnetic lifter FX-C175circular
Add to favorites
Compare this product
Characteristics
- Type of commutation
- manually switched
- Shape
- circular
- Lifting force
175 kgf
Description
Product overview
FX-C175 lifting magnet is equipped with a round, multi-pole anchorage surface specifically designed for lifting elements with circular or flange-shaped geometries. The design ensures an optimum distribution of the lifting force for improved grip and safety.
Applications
Load and contact area information
The lifting capacity of the FX-C175 magnet (maximum 175 kg) is valid only when there is a full contact surface between the magnet and the workpiece. For workpieces with a smaller contact area, a maximum load of 3.5 kg per cm² can be calculated.
Standards and origin
Manufactured in Germany. Complies with CE/EN 13155 and MRL 2006/42 EWG, ensuring conformity with applicable safety and machinery regulations for industrial use.
Documentation
Technical drawing for the FX-C series is available as a PDF in the product documentation.
Caractéristiques / spécifications techniques
FX-C175 lifting magnet is equipped with a round, multi-pole anchorage surface specifically designed for lifting elements with circular or flange-shaped geometries. The design ensures an optimum distribution of the lifting force for improved grip and safety.
Applications
- Rings
- Bushings
- Bearing housings
- Flange plates
- Other similar circular or ring-shaped parts
Load and contact area information
The lifting capacity of the FX-C175 magnet (maximum 175 kg) is valid only when there is a full contact surface between the magnet and the workpiece. For workpieces with a smaller contact area, a maximum load of 3.5 kg per cm² can be calculated.
Standards and origin
Manufactured in Germany. Complies with CE/EN 13155 and MRL 2006/42 EWG, ensuring conformity with applicable safety and machinery regulations for industrial use.
Documentation
Technical drawing for the FX-C series is available as a PDF in the product documentation.
Caractéristiques / spécifications techniques
- Model: FX-C175
- Maximum capacity: 175 kg
- Anchorage surface: round, multi-pole
- Suitable for: rings, bushings, bearing housings, flange plates and similar parts
- Load rule for limited contact area: up to 3.5 kg per cm²
- Standards: CE/EN 13155; MRL 2006/42 EWG
- Country of manufacture: Germany
