Diaphragm seal with threaded connection DT101

for pressure gaugesprocess

DT-101 diaphragm seal is designed in economic type to save cost for application in highly viscous process industries. It is easy to assemble with pressure gauges, pressure switches, and pressure instrument. Technical Data Instrument connection: female thread 1/4" to 1/2" BSP or NPT Process connection: 1/4" to 1/2" BSP or NPT, option available Temperature limited: -40~+150℃ Pressure range limited: Maximum up to 40 kg/cm2 (for pressure gauge); Minimum 0~6 kg/cm2 Material: body-SS316 (standard), option: SS316L, Hastelloy C276, others on request Membrane: SS316L (standard); Options- Hastelloy C276, tantalum and others on request.
