Diaphragm seal with threaded connection DT103
for pressure gaugesprocess

diaphragm seal with threaded connection
diaphragm seal with threaded connection
diaphragm seal with threaded connection
diaphragm seal with threaded connection
Add to favorites
Compare this product


Characteristics

Installation system
with threaded connection
Other characteristics
for pressure gauges
Field
process
Pressure

Max.: 350 bar (5,076.32 psi)

Min.: 0 bar (0 psi)

Description

DT-103 diaphragm seal is designed to be used in highly vis-cous process industries. It is easy to assemble with pressure gauges, pressure switches, and pressure instruments. Technical Data Instrument connection: female thread Va to W BSP or NPT Process connection: Vz" to 2” BSP male thread Température limited: -40~+150°C Pressure range limited: (for pressure gauge) Material: body-SS316(standard) Option: SS316L,Hastelloy C276, and others on request Membrane: SS316L(standard) Option: Hastelloy C276, tantalum and others on request
