Circular saw SWT-R series

for plasticsfor PE pipesfor pipes

The Saddle Radius Saw is a workshop-grade cutting machine designed for precise saddle cutting of large-diameter thermoplastic pipes, offering accurate, efficient and easy operation for pipe fitting fabrication. It is suitable for cutting HDPE, PP, PPR and PVDF pipes and supports two radius models for different pipe ranges.

Key features

• High-precision cutting and smooth cutting edges suitable for pipe fittings (cutting tolerance indicated ±0.5 mm).
• Efficient processing capability and fast, reliable operation for workshop use.
• Unique saddle cutting method for accurate fitment preparation.
• Electric cutting feed for consistent and controllable results.

Applications

• Cutting HDPE, PP, PPR and PVDF pipes for pipe fitting fabrication, saddle fitting preparation and workshop assembly.

Specifications

• Models: SWT-R315 (R315A) and SWT-R630 (R630A) — SWT-R series.
• Maximum cutting diameter: 315 mm (SWT-R315) / 630 mm (SWT-R630).
• Maximum cutting radian: R315A (for 315 model) / R630A (for 630 model).
• Cutting feed speed: Electric.
• Working voltage: 380 VAC, 3P+N+PE, 50 Hz.
• Total power: 2.2 kW (both models).
• Total weight: SWT-R315 — 1150 kg; SWT-R630 — 1140 kg.
• Warranty: 2 years quality guarantee; technical support available.
