Hot plate welding machine SWT-S315

automaticfor pipesfor thermoplastics

Product overview
The SWT-S315 is a saddle fusion welding machine engineered for workshop fabrication of reducing tees and similar fittings. It is suitable for thermoplastic pipes made of HDPE, PP, PPR and PVDF and designed for repetitive, controlled production in fitting and distributor manufacturing environments.

Key functions

• Hydraulic clamping system for secure fixation of the main pipe
• Automatic welding cycle with integrated safety protections
• Manual movement and release device for the heating plate to accept male/female sockets
• Integrated drilling/tapping and welding sequence to complete tee fabrication

Standard composition and product features

• Configured for fabrication of 90° reducing tees in a workshop setting
• Combined welding and taping functions to perform end-to-end production steps
• Robust machine bed and precise slide on linear guides for stable, accurate movement
• Hydraulic jaws to lock the main pipe; manual jaw to secure the branch pipe
• Manual operation available for selected movements and adjustments
• Reduced-tee driller included; convex and concave dies available on request

Applications

• Pipe fitting factories and fitting manufacturers
• Production of water distributors, splitters and manifold fittings

Technical data / specifications

• Model: SWT-S315
• Welding application: Reducing tee (fabrication of reducing tees)
• Power supply: 220 V, 50/60 Hz
• Rated power: 2.8 kW
• Main pipe OD range: 90 mm – 315 mm
• Branch pipe OD range: 32 mm – 140 mm
• Max. heating temperature: 270 °C
• Materials supported: HDPE, PP, PPR, PVDF
• Weight: 350 kg
• Warranty: 2-year quality warranty
