Vertical drilling machine KB 32 SF

column typevariable speedcompact

Product overview
The KB-S series comprises reliable column drills for workshops and industrial applications. Compact construction, high rigidity and precise workmanship make these machines suitable for general metalworking and production tasks.

Highlights

• 32 mm drilling capacity
• Digital speed display with 8 speed levels
• Tapping mode with automatic reversal
• Integrated LED work light
• Supplied with drill chuck and drill vise

Product details

• Cast-iron construction and precise machining for stability and accuracy
• Heavy, precision-ground worktable with diagonal T-slots
• Very smooth height adjustment of the table, even under load
• Large base plate with ground mounting area and parallel T-slots
• Forward/reverse operation and automatic reversal for thread cutting
• Hardened and ground spindle and spindle nose
• Robust belt drive and quiet, powerful motor
• Speed range (8 levels): 125, 250, 380, 500, 580, 850, 1250, 1960 1/min

Standard equipment

• Drill chuck
• Tool-holder pin
• Drill press vise
• Thread cutting function (selectable from control panel)
• Service tools
• Coolant system

Technical specifications

• Drilling capacity: 32 mm
• Tapping capacity (max.): M24
• Table area: 330 mm x 330 mm
• Spindle nose to table: 813 mm
• Spindle nose to base: 1,236 mm
• Throat depth: 265 mm
• Column diameter: 100 mm
• Quill stroke: 150 mm
• Speed range (headstock): 125 - 1,960 1/min (8 steps)
• Spindle mount: 3 MT
• Main motor rating: 1.5 kW
• Overall dimensions (L x W x H): 1 m x 0.6 m x 2.1 m
• Weight: 345 kg
