Tabletop power supply LPX-60P60B3

DCsingle-outputadjustable

Brief introduction
The LPX-60P60B3 is a compact, precision high-voltage power supply intended for X‑ray and electron beam applications. It provides an adjustable output from 0 to 60 kV with a maximum current of 1.0 mA and maximum output power of 60 W. The unit offers very low ripple (≤0.1% P‑P) and tight temperature stability (≤25 ppm/°C), suitable for integration into medical imaging and laboratory instrumentation.

Applications

• Medical imaging systems (X‑ray generators)
• Industrial inspection and non‑destructive testing
• Scientific research and laboratory instruments
• Electron beam equipment
• Materials analysis systems

Key specifications

• Model: LPX-60P60B3
• Output voltage: 0–60 kV
• Output current: up to 1.0 mA
• Maximum output power: 60 W
• Input voltage: 24 VDC ±10%
• Input current: max 8.0 A
• Stability: <0.01%/hr after 0.5 hr; <0.02% over 8 hrs
• Temperature coefficient: ≤25 ppm/°C
• Ripple: 0.1% of max output voltage (P‑P)
• Voltage load regulation: 0.01% (no load to rated load)
• Voltage input regulation: ±0.01% (±10% input variation)
• Current load regulation: 0.01% (no load to rated load)
• Current input regulation: ±0.01% (±10% input variation)
• Control & communication: dual analog/digital control, local potentiometer, remote 0–10 VDC input, RS‑232/RS‑485 supported
• Protections: interlock and overload protection
• Dimensions: 75 × 139 × 218 mm
• Weight: 3.5 kg
