Benchtop power supply LPX-10P10B3

DCsingle-outputadjustable

Brief introduction
The LPX-10P10B3 is a compact high-voltage power supply providing adjustable output from 0 to 10 kV with a maximum current of 1.0 mA and maximum power of 10 W. It offers long-term stability (≤0.01%/hr after 0.5 hr warm-up) and low ripple (0.1% P-P). Dual control modes (local potentiometer and remote 0–10 Vdc) and support for CAN, RS-232 and RS-485 enable flexible system integration. The unit weighs 1.6 kg, uses natural cooling and includes interlock protection, suitable for laboratory and industrial use in space-constrained setups.

Specifications
Input Voltage: 24 Vdc ±10%
Input Current: Max 2.0 A
Output Voltage Range: 0–10 kV
Output Current: Max 1.0 mA
Output Power: Max 10 W
Stability: <0.01%/hr after 0.5 hr warm-up; <0.02% over 8 hrs
Temperature Coefficient: ≤25 ppm/°C
Ripple Voltage: 0.1% of maximum output voltage (P-P)
Voltage Load Regulation: 0.01% (no load to rated load)
Voltage Input Regulation: ±0.01% (input variation ±10%)
Current Load Regulation: 0.01%
Current Input Regulation: ±0.01%
Dimensions: 65 × 115 × 165 mm
Weight: 1.6 kg

Key features

• Model: LPX-10P10B3
• Dual analog/digital control with local potentiometer and remote 0–10 Vdc input
• Communications: CAN, RS-232, RS-485
• Natural cooling and interlock protection for safe operation
• Compact footprint for space-limited installations

Applications

• Educational laboratories and physics experiments
• Material testing and small-scale research
• Low-voltage electron beam systems
• Industrial quality control requiring stable high-voltage output
