Ultrasonic NDT inspection device A1410 PULSAR

The world-first ultrasonic pulse velocity testing instrument for couplant-free on-site. A compact, ergonomic and easy to handheld ultrasonic pulse velocity tester for quality assessment of concrete compliant with valid international standards. The instrument is made of light-weight shockproof plastic and operates two drypoint-contact transducer arrays for through-transmitting up to 2 meters of concrete. A compact, ergonomic and easy to handheld ultrasonic pulse velocity tester for quality assessment of concrete compliant with valid international standards. The instrument is made of light-weight shockproof plastic and operates two dry-point-contact transducer arrays for through-transmitting up to 2 meters of concrete. Wear resistant wearproof ceramic tips of the transducers are insensitive to the surface condition and allow comfortable and robust operation on site by arbitrary surface condition. Hence, there is no need to apply coupling gel to prepare object surface for testing; The device possesses non-volatile memory allowing storing of 50,000 measurements (the results can be grouped) and USB port for transferring measured data to the external PC; The instrument is suitable for compressive strength evaluation of concrete. The evaluation is based on correlation of longitudinal ultrasonic wave velocity in concrete with its mechanical properties; Measurements are performed by thru-transmission of inspection object by means of two transducer arrays. Further possible areas of application of A1410 are: - Evaluation of the load-carrying ability of concrete backbones and posts; - Evaluation of porosity and fissuring of concrete; - Evaluation of anisotropy in composite materials; - Evaluation of the concrete aging. The A1410 PULSAR complies with following international standards. The given technical specifications conform with the following international standards: - DIN EN 12504 4; - BS 1881: Part 203 : 1986; - ASTM C597 16; - IS 13311 1. Technical features: - Array of 7 x DPC transducers, daisy wheel pattern; - Transmitter pulse voltage, V 400; - Operating frequency, kHz 50; - Set delay range, µs 0 to 20; - Time shift, µs 0 to 500; - Adjustable range of the base size, mm 50 to 2500; - Maximum averaging factor 64; - Automatic Gain Control (AGC) switchable; - Maximum thickness of the inspection object, m 2.5; - Indication resolution of the propagation time of ultrasonic waves, µs 0.1; - Indication resolution of the propagation velocity of ultrasonic waves, m/s 10; - The measurement range of the time propagation of the longitudinal ultrasonic wave, µs 10 to 700; - The measurement range of the time propagation of the longitudinal ultrasonic wave, m/s 1000 to 15000; - Limits of the absolute permitted inaccuracy of the propagation time of ultrasonic waves, µs, where t is the measured time value, µs ±(0.02∙t+0.1); - Limits of the absolute permitted inaccuracy of the propagation velocity of ultrasonic waves, m/s, where c is the measured velocity value, m/s ε is the relative measurement inaccuracy of the base ±(0.02+ε)∙с+10); - Rated supply voltage; - Period of continuous operation with the display brightness 80%, temperature 25°C, hours 16; - Display 2.8”, 320×240 pixel; - Overall dimensions of the electronic unit, mm., max. 230×125×65; - Weight of the electronic unit, gr., max. 420; - Mean time between failures, hours 18,000; - Regular service life, years 5. Accessories: - Electronic unit of the Ultrasonic pulse velocity tester A1410; - PulsarAntenna array M1001 0.05A0D25PL; - EMO-LEMO single cable 3 m; - Adapter 220 V – USB; - Cable USB A – Micro B; - Hard case; - CD with documentation; - Warranty certificate; - Operation Manual.
