Axial PC fan 9LG0648P4S001cooling48VDCaluminum
Add to favorites
Compare this product
Characteristics
- Configuration
- axial
- Function
- cooling
- Supply voltage
- 48VDC
- Material
- aluminum
- Air flow
1.4 m³/min
(49.441 ft³/min)
Description
Frame thickness [mm]
25
Frame material
Aluminum
Operating voltage range [V]
36～72
Rated current [A]
0.18
Rated input [W]
8.64
Rated speed [min-1]
11000
Max. airflow [m3/min]
1.4
Max. airflow [CFM]
49.4
Max. static pressure [Pa]
305
Max. static pressure[inchH2O]
1.224
SPL [dB(A
53
Operating temperature[˚C]
-20～+70
Expected life[h]
180000/60℃ (215000/40℃)
Mass [g]
100
Sensor type
Pulse sensor
PWM control function
Yes
Ribbed
No
Catalogs
DC Fan Catalog
247 Pages
