Robotic palletizer MOTOMAN-GP series

for bottle packsfor bottlesfor cardboard boxes

Product overview
A 6-axis handling and palletizing robot family offering multiple reach and payload variants. With reinforced wrist torque and modular core components, the series supports bulk part gripping, insertion, assembly, grinding and machining tasks. The design minimizes cable routing between robot and control cabinet to simplify maintenance and streamline cell integration.
Features

• Wide working envelope to support efficient processing lines
• Reinforced wrist torque for handling various large workpieces
• Reduced cabling between robot and control cabinet for easier maintenance and simpler installation
• Compact footprint enabling operation in constrained spaces while accommodating large workpiece.

Technical specifications

• Axes: 6
• Horizontal reach: 2446 mm / 2710 mm / 2702 mm / 2912 mm / 2702 mm
• Payload range: 180–280 kg depending on variant
• Robot mass: 1020–1345 kg depending on variant
• Repeatability (repositioning): ±0.05 mm
• Protection: Body IP54; wrist IP67
• Mounting: Floor-mounted
• Typical uses: material handling, pick & pack, palletizing, assembly and sub-packing operations
