Turntable wrapping machine CTP1650F-L

automaticwith electromagnetic brakingfor the food and beverage industry

Overview
Pallet wrapping machine with integrated scale for simultaneous weighing and wrapping. The system permits weighing during the wrapping cycle, reducing pallet handling and improving throughput. Optional label printer available for immediate identification and traceability.
Features

• Integrated scale enables weighing during the wrapping process
• Simultaneous weighing and wrapping saves material handling time
• Optional label printer for immediate pallet labelling
• Improves logistics efficiency and reduces loss during transport
• Provides dustproof and moisture-proof protection while optimising packaging material use

Technical data

• Turntable Size: 1650 mm
• Turntable Speed: 0–12 RPM (adjustable)
• Maximum wrapping speed: 20–30 loads/hour
• Maximum pallet size: 1.1 x 1.2 m
• Maximum wrapping height: 2000 mm
• Max load weight: 2000 KG
• Power supply: 110/220/380 V 50 Hz
• Power: 1.55 KW
• Machine size: L2545 x W1650 x H2815 mm
• Machine weight: 550 Kg
• Standard pre-stretch: 250–300%
• Standard film width: 500 mm
• Weighing accuracy: 2/1000 kg
• Turntable height: 330 mm
