IR photovoltaic detection module IC023 series

InAsfor gas analysisuncooled

IC02310-01 is a detection module featuring an uncooled photovoltaic IR detector chip based on an InAs heterostructure, integrated with an ASIC-type (application-specific integrated circuit), transimpedance amplifier. This module has a TO39 cap featuring a 3 deg. wedged sapphire window. Features Spectral range: 2.3 to 3.5 μm RoHS-compliant III-V material Front-side illuminated ASIC-type electronics Programmable gain DC coupling (AC coupling on request) Compact, surface-mount type package Long-term stability and reliability High ambient operating and storage temperature Low power consumption Possibility of mounting optical filter Applications Gas detection, monitoring and analysis: H2O, HF, CH4, C2H2, C2H4, C2H6, NH3 Combustion process control Green energy Medical laser control
