Managed switch 9505-24GP4XS

4 ports24 portslayer 2

Product Highlights

• Next-Gen 802.3bt PoE++ Power: 8 x 90W btPoE ports and 16 x PoE+ ports to power high-demand devices such as Wi‑Fi 6/7 APs and PTZ cameras without extra cabling.
• 10G SFP+ High-Speed Uplinks: 4 x 10G SFP+ slots deliver low-latency, wire-speed throughput for bandwidth-intensive streaming and large file transfers.
• Fiber Ring Redundancy: Multiple fiber ring ports support automatic failover to backup paths for high availability; industrial models operate from -40°C to 70°C for continuous reliability.
• Advanced Traffic Control & Security: IGMP Snooping and L2/L3/L4 Access Control Lists (ACL) optimize bandwidth and protect against malicious traffic.
• Flexible Smart Management: Web GUI, CLI, and standard SNMP remote management for real-time troubleshooting and easy oversight.

Overview
This 9505-24GP4XS series is a high-performance managed PoE switch offering 24 x 10/100/1000 Mbps RJ45 PoE ports with IEEE 802.3bt/at/af compliance and 4 x 10G SFP+ uplink fiber slots to support copper and fiber architectures. It provides robust btPoE power (up to 90W on btPoE ports) to power high-power devices such as Wi‑Fi 6/7 access points, PTZ cameras, LED displays and IoT gateways. The switch includes Layer 2 features (VLAN, Link Aggregation, Spanning Tree, QoS, IGMP Snooping, ACL) to optimize bandwidth and ensure quality and security for critical applications.

With high switching capacity and wire-speed forwarding, the unit delivers stable, low-latency performance under heavy multi-user traffic, suitable for real-time video streaming and mission-critical systems. Management options include Web GUI, CLI and SNMP; remote firmware upgrade, configuration backup and restore are supported. The metal housing and thermal design support reliable 24/7 operation in rack-mount form factor for centralized network management. Advanced btPoE capability provides a future-proof solution for powering next‑generation devices in enterprise, campus, surveillance and smart city networks.

Features

• 10G SFP+ Interface: 10G fiber SFP+ delivers wire‑speed throughput with low latency for data-intensive applications; cost-effective alternative to specialized SAN solutions.
• SNMP Remote Management: Supports monitoring and remote configuration via SNMP for flexible control and real-time alerts.
• IGMP Snooping: Reduces multicast traffic by forwarding only to intended recipients, improving network efficiency for streaming and high-bandwidth IP applications.
• ACL: L2/L3/L4 Access Control List for granular traffic filtering based on MAC/IP/port criteria to block unwanted or malicious traffic.
• Multiple Fiber Ring Ports: Enables redundant fiber rings and automatic switching to maintain continuous communication and minimize downtime.
• IEEE 802.3bt: Supports direct powering of high-power devices via Ethernet cable with intelligent PoE management (power monitoring, scheduling, PD alive check, power on/off control).

Ordering Information
9505-24GP4XS-A-C : Managed 8 x 10/100/1000 btPoE & 16 x 10/100/1000 PoE+ & 4 x 1G/10G SFP+ Industrial Switch, Metal
9505-24GP4XS-AA-C : Managed 8 x 10/100/1000 btPoE & 16 x 10/100/1000 PoE+ & 4 x 1G/10G SFP+ Industrial Switch, Metal
9505-24GP4XS-D-I : Managed 8 x 10/100/1000 btPoE & 16 x 10/100/1000 PoE+ & 4 x 1G/10G SFP+ Industrial Switch, Metal

Specifications

• Standards: IEEE 802.3 / 10BASE-T; IEEE 802.3u / 100BASE-TX; IEEE 802.3ab / 1000BASE-T; IEEE 802.3z / 1000BASE-SX/LX; IEEE 802.3ae / 10GBase-SR/LR/ER; IEEE 802.3 Nway (Auto-negotiation); IEEE 802.3x Flow Control; IEEE 802.3ad Link Aggregation; IEEE 802.3af (PoE); IEEE 802.3at (PoE+); IEEE 802.3bt (Type 3/4, 4PPoE); IEEE 802.3az (EEE); IEEE 802.1AB (LLDP); IEEE 802.1ad (QinQ); IEEE 802.1D/w/s (STP/RSTP/MSTP); IEEE 802.1p (COS); IEEE 802.1Q (VLAN); IEEE 802.1X (Network Access Control).
• Ports / Interface: 24 x 10/100/1000 PoE RJ45; 4 x 1G/10G SFP+; 1 x RS232 Console Port; 1 x USB Port.
• Digital I/O: Digital Input: 2 pairs, Dry Contact; Digital Output: 1 x Relay Output (1A@24V DC).
• LED Panel: POST, PWR1, PWR2, ALM, 1000/PoE, LINK/ACT.
• Power Input: 9505-24GP4XS-A-C / AA-C: 100~240V AC, 50/60Hz; 9505-24GP4XS-D-I: 48~57V DC.
• Power Consumption (System Only): A-C: 22W; AA-C: 29W; D-I: 16W.
• PoE Functions: PoE Scheduling, PD Alive Check, Power delay, PoE Power on/off, Fast PoE, Perpetual PoE, Power budget control per system and per port.
• PoE++ Allocation: Ports 1–8 support IEEE 802.3af/at/bt (btPoE up to 90W); Ports 9–24 support IEEE 802.3af/at.
• PoE Power Budget (by version): 9505-24GP4XS-A-C: AC 100~240V, 450W @ 50°C; 9505-24GP4XS-AA-C: AC 100~240V, 685W @ 50°C; 9505-24GP4XS-D-I: DC 48~57V, 685W @ 70°C.
• Housing / Protection: Metal enclosure, IP30 protection.
• Fan: A-C / AA-C: 4 fans; D-I: fanless (0 fans).
• Operating Temperature: A-C / AA-C: 0°C ~ 50°C (32°F ~ 122°F); D-I: -40°C ~ 70°C (-40°F ~ 158°F).
• Storage Temperature: -40°C ~ 85°C (-40°F ~ 185°F).
• Operating Humidity: 5 to 95% RH (non-condensing); Storage Humidity: 5 to 95% RH (non-condensing).
• Weight: A-C: 4.14 kg (9.13 lb); AA-C: 4.66 kg (10.27 lb); D-I: 3.74 kg (8.25 lb).
• Dimension (W x H x D): 440 x 44 x 284 mm (17.3 x 1.73 x 11.2 in).
