Round sling

endlesspolyester

Introduction
Xintai Taida Mirso rigorously tests every polyester round lifting sling to 7x its 1-ton WLL. The endless (continuous loop) design eliminates end terminations and weak points, making these slings suitable for lifting awkward loads or items without dedicated attachment points. ISO and TUV-CE certified options and official test reports are available on request.

Parameter
Table (values for various Working Load Limits and lifting configurations):
Factor: 1.0, 0.8, 2.0, 1.4, 1.0, 0.7, 0.5, 1.4, 1.12, 1.0, 0.8
WLL 1T: 1.0, 0.8, 2.0, 1.4, 1.0, 0.7, 0.5, 1.4, 1.12, 1.0, 0.8
WLL 2T: 2.0, 1.6, 4.4, 2.8, 2.0, 1.4, 1.0, 2.8, 2.24, 2.0, 1.6
WLL 3T: 3.0, 2.4, 6.1, 4.2, 3.0, 2.1, 1.5, 4.2, 3.36, 3.0, 2.4
WLL 4T: 4.0, 3.2, 8.0, 5.6, 4.0, 2.8, 2.0, 5.6, 4.48, 4.0, 3.2
WLL 5T: 5.0, 4.0, 10, 7.1, 5.0, 3.5, 2.5, 7.1, 5.60, 5.0, 4.0
WLL 6T: 6.0, 4.8, 12, 8.4, 6.0, 4.2, 3.0, 8.4, 6.72, 6.0, 4.8
WLL 8T: 8.0, 6.4, 16, 11.2, 8.0, 5.6, 4.0, 11.2, 8.96, 8.0, 6.4
WLL 10T: 10, 8.0, 20, 14.0, 10, 7.0, 5.0, 14.0, 11.20, 10, 8.0
WLL 12T: 12, 9.6, 24, 16.8, 12, 8.4, 6.0, 16.8, 13.44, 12, 9.6
WLL 15T: 15, 12, 30, 21.0, 15, 10.5, 7.5, 21.0, 16.80, 15, 12
WLL 20T: 20, 16, 40, 28.0, 20, 14.0, 10.0, 28.0, 22.40, 20, 16
WLL 30T: 30, 24, 60, 42.0, 30, 21.0, 15.0, 42.0, 33.60, 30, 24
WLL 50T: 50, 40, 100, 70.0, 50, 35.0, 25.0, 70.0, 56.00, 50, 40
WLL 60T: 60, 48, 120, 84.0, 60, 42.0, 30.0, 84.0, 67.20, 60, 48
WLL 80T: 80, 64, 160, 112.0, 80, 56.0, 40.0, 112.0, 89.60, 80, 64
WLL 100T: 100, 80, 200, 140.0, 100, 70.0, 50.0, 140.0, 112.00, 100, 80

Standards

• Q1: Do you have relevant certificate? A1: TUV-CE certificate for most products; ISO9001 and ISO14001. Official quality test reports available.
• Q2: Can I have a sample for testing? A2: Yes, samples available; customer normally pays express costs.
• Q3: Can you provide OEM or ODM service? A3: Yes, OEM/ODM services available; logos can be added per agreement.
• Q4: Do you have inspection procedures for the manufacture line? A4: Complete testing process and inspection procedures are implemented.

Technical specifications

• Commercial name: Round Sling (endless)
• Type: Polyester round lifting sling (endless)
• Color: Red
• Design: Endless continuous loop (no end terminations)
• Typical rated Working Load Limits (WLL): 1T, 2T, 3T, 4T, 5T, 6T, 8T, 10T, 12T, 15T, 20T, 30T, 50T, 60T, 80T, 100T (see Parameter table for lifting multipliers by angle)
• Test / Safety: Manufacturer tests slings to 7x the 1-ton WLL (manufacturer test statement)
• Certifications / Quality management: TUV-CE (most products), ISO9001, ISO14001; official quality test reports available
• Applications: Lifting awkward loads without attachment points; general webbing sling lifting operations in industrial environments
