Electric cut-off saw SDT 275

for metalsfor steel

Product overview
Cut-off saw designed for cutting bars, profiles and steel reinforcements used in PVC window manufacture. Compact layout with pivoting cutting head for angled cuts.

Key features

• Pivoting range: 45° right / 45° left (±45°)
• Double-speed motor: 45 / 90 RPM, speed selectable according to material
• Cutting capacity: square profile up to 70 x 70 mm
• Standard saw blade diameter: Ø275 mm (included)
• Application: cutting reinforcement steels, bars and profiles for PVC windows

Standard accessories

• Saw blade Ø275 mm (supplied)
• Manual material clamping system
• Saw blade lubrication system

Optional accessories

Technical specifications

• Model: SDT 275
• Pivoting range: ±45°
• Motor speeds: 45 RPM / 90 RPM (double-speed), selectable
• Cutting capacity: up to 70 x 70 mm (square profile)
• Standard blade diameter: Ø275 mm (included)
• Material clamping: manual
• Saw blade lubrication system
