Electric pressure booster pump unit LFP300GPD

electrically-poweredfor water systemsfor water

Product overview
LFP300GPD is a 24V DC reverse osmosis (RO) booster pump for increasing feed pressure in RO systems. The product page provides multiple product images, dimension drawings and parameter tables covering both self-priming and normal variants.

Key parameters

• Self-priming type — LFP1300S: Inlet 0 MPa | Working pressure 0.5 MPa | Working current ≤3.5A | Working flow ≥2600 mL/min | Open flow ≥3200 mL/min | Bypass pressure 0.8–1.0 MPa | Max current ≤4.5A | Self-priming height ≥3.0 m
• Normal type — LFP1300J / LFP1300JD: Inlet 0.2 MPa | Working pressure 0.5 MPa | Working current ≤2.3A | Working flow ≥2700 mL/min | Open flow ≥4000 mL/min | Bypass pressure 0.85–1.05 MPa | Max current ≤3.2A
• Normal type — LFP1300J-V: Working flow ≥3500 mL/min | Bypass pressure 0.9–1.1 MPa
• Normal type — LFP1300W-P / LFP1300W: Working current ≤2.3–2.4A | Open flow up to ≥4000 mL/min | Bypass pressure 0.85–1.05 MPa

Dimensions / drawings
Multiple dimension drawings and installation views are available on the product page to support mechanical integration and mounting checks.

Related applications

• HVAC
• Cleanroom
• Refrigeration
• Building automation
• Water & wastewater

Features / technical specifications

• Model: LFP300GPD
• Product family: 24V DC RO booster pump (reverse osmosis booster)
• Rated voltage: 24V DC
• Available variants: self-priming and normal types; related models include LFP50GPD, LFP75GPD, LFP100GPD, LFP150GPD, LFP200GPD, LFP300GPD-A, LFP300GPD, LFP400GPD, LFP600GPD, etc.
• Typical working pressure shown: 0.5 MPa
• Example working currents: ≤2.3A to ≤3.5A; working flows: ≥2600–≥2700 mL/min; open flows up to ≥4000 mL/min for some models
• Bypass pressure ranges: approx. 0.8–1.1 MPa depending on model
• Max current examples: ≤3.2A and ≤4.5A depending on model
• High-resolution product images and multiple dimension drawings provided
• Brand: LEFOO
