MIG-MAG welding power supply StarT-402-C Mastersolid wirethree-phaseDC
Add to favorites
Compare this product
Characteristics
- Technique
- MIG-MAG
- Consumables
- solid wire
- Power supply
- three-phase
- Output current
- DC, pulsed DC
- Material
- for steel, for stainless steel, for aluminum
- Other characteristics
- with integrated display, with wire feeder
- Intensity
Min.: 15 A
Max.: 400 A
Description
Product description
The QINEO StarT welding power source offers an easy entry into manual pulse welding. In addition to the standard processes, four preconfigured CLOOS welding processes are available to avoid extensive parameter searches. A module mounted on the power unit integrates the control interface, a powerful wire drive and the holder for a 15-kg wire spool. A range of optional components and functions enables adaptation of the QINEO StarT to specific manual welding tasks.
Benefits
Technical details
Base materials: Aluminium; chrome-nickel; steel
Processes: Control Weld; Rapid Pulse Weld; Rapid Weld; Root Weld; Vari Weld
Methods: MIG brazing; MIG/MAG single-wire; MIG/MAG single-wire pulse
Product category: Welding power source
Design: Internal wire drive
Application: Manual
Dimensions L/W/H: 805 x 348 x 643 mm
Supply cable: 4 x 6 mm²
Weight: 75 kg
Insulation class: F
Cooling type: F
Open-circuit voltage: 78.7 V
Mains protection (400 V): 32 A
Supply voltage: 380 V - 400 V / 50 Hz / 3-phase
Protection rating: IP 23
Welding current: 15 A - 400 A
Welding current 100% ED: 400 A
Features / technical specifications
The QINEO StarT welding power source offers an easy entry into manual pulse welding. In addition to the standard processes, four preconfigured CLOOS welding processes are available to avoid extensive parameter searches. A module mounted on the power unit integrates the control interface, a powerful wire drive and the holder for a 15-kg wire spool. A range of optional components and functions enables adaptation of the QINEO StarT to specific manual welding tasks.
Benefits
- Design that balances component cost and welding performance
- Faster setup with preconfigured parameters for four CLOOS welding processes (Control Weld; Rapid Pulse Weld; Rapid Weld; Root Weld; Vari Weld)
- Integrated wire drive in the power source ensures slip-free, powerful wire feeding
- Simple and intuitive operation via the MasterPlus Compact control module
- Modular construction and extensive accessories for flexible application and configuration
Technical details
Base materials: Aluminium; chrome-nickel; steel
Processes: Control Weld; Rapid Pulse Weld; Rapid Weld; Root Weld; Vari Weld
Methods: MIG brazing; MIG/MAG single-wire; MIG/MAG single-wire pulse
Product category: Welding power source
Design: Internal wire drive
Application: Manual
Dimensions L/W/H: 805 x 348 x 643 mm
Supply cable: 4 x 6 mm²
Weight: 75 kg
Insulation class: F
Cooling type: F
Open-circuit voltage: 78.7 V
Mains protection (400 V): 32 A
Supply voltage: 380 V - 400 V / 50 Hz / 3-phase
Protection rating: IP 23
Welding current: 15 A - 400 A
Welding current 100% ED: 400 A
Features / technical specifications
- Integrated wire drive in the housing for slip-free, powerful wire feeding
- MasterPlus Compact control module for simple and intuitive operation
- Holder for 15-kg wire spool
- Modular design with numerous optional components and functions
- Supported processes: Control Weld, Rapid Pulse Weld, Rapid Weld, Root Weld, Vari Weld
- Suitable for manual welding; methods: MIG brazing, MIG/MAG single-wire, MIG/MAG single-wire pulse
