Load support BSB series

conveyor beltmodular

The Belt Support Bar (BSB) supports the conveyor belt at the load zone to reduce belt sag between idlers, restore the load zone to a sealed position, limit dust escape and reduce uneven skirting wear. It is a modular, low-maintenance support system designed to fit between existing idlers and simplify installation and service.

Features and benefits

• No equipment modification needed. Fits between existing idlers without modifying existing equipment.
• Modular design. Telescoping tubing provides adjustable length and rotating hinges enable adjustable approach and bar angles to match the load zone setup.
• Easy to install. A pair of BSBs mounts to the conveyor structure with only four bolts; there is no need to lift the belt or move idlers.
• Low maintenance. 1" (25 mm) UHMW wear bars provide long life and require virtually no adjustment.

Design & materials

• Telescoping tubing for adjustable length.
• Rotating hinges for approach and bar angle adjustment.
• 1" (25 mm) UHMW wear bars for durable belt contact.

Available sizes (ordering info)

• SIZE 1 — Ordering Number: BSB-1 — Item Code: 112918 — Belt Width: 18–30 in (450–750 mm) — Troughing Angles: 20°, 35° and 45° (depending on belt width) — Weight: 22.7 kg (50.1 lbs)
• SIZE 2 — Ordering Number: BSB-2 — Item Code: 112919 — Belt Width: 30–36 in (750–900 mm) — Troughing Angles: 20°, 35° and 45° (depending on belt width) — Weight: 23.8 kg (52.4 lbs)
• SIZE 3 — Ordering Number: BSB-3 — Item Code: 112920 — Belt Width: 36–48 in (900–1200 mm) — Troughing Angles: 20°, 35° and 45° (depending on belt width) — Weight: 24.3 kg (53.6 lbs)
• SIZE 4 — Ordering Number: BSB-4 — Item Code: 112921 — Belt Width: 42–60 in (1050–1500 mm) — Troughing Angles: 20°, 35° and 45° (depending on belt width) — Weight: 27.8 kg (61.3 lbs)
• SIZE 5 — Ordering Number: BSB-5 — Item Code: 112922 — Belt Width: 60–72 in (1500–1800 mm) — Troughing Angles: 20°, 35° and 45° (depending on belt width) — Weight: 30.5 kg (67.2 lbs)
• SIZE 6 — Ordering Number: BSB-6 — Item Code: 112923 — Belt Width: 72–96 in (1800–2400 mm) — Troughing Angles: 20°, 35° and 45° (depending on belt width) — Weight: 37.9 kg (83.5 lbs)

CEMA selection (belt width to BSB size mapping)
CEMA Class C

• 18 in / 450 mm — SIZE 1 at 20°, 35° and 45°
• 24 in / 600 mm — SIZE 1 at 20°, 35° and 45°
• 30 in / 750 mm — 20° SIZE 1; 35° SIZE 1; 45° SIZE 2
• 36 in / 900 mm — 20° SIZE 2; 35° SIZE 2; 45° SIZE 3
• 42 in / 1050 mm — 20° SIZE 3; 35° SIZE 3; 45° SIZE 4
• 48 in / 1200 mm — 20° SIZE 3; 35° SIZE 4; 45° SIZE 4
• 54 in / 1350 mm — 20° SIZE 4; 35° SIZE 4; 45° SIZE 4
• 60 in / 1500 mm — 20° SIZE 4; 35° SIZE 4; 45° SIZE 5

CEMA Class D

• 24 in / 600 mm — SIZE 1 at 20°, 35° and 45°
• 30 in / 750 mm — 20° SIZE 1; 35° SIZE 2; 45° SIZE 2
• 36 in / 900 mm — 20° SIZE 2; 35° SIZE 2; 45° SIZE 3
• 42 in / 1050 mm — 20° SIZE 3; 35° SIZE 3; 45° SIZE 4
• 48 in / 1200 mm — 20° SIZE 3; 35° SIZE 4; 45° SIZE 4
• 54 in / 1350 mm — 20° SIZE 4; 35° SIZE 4; 45° SIZE 4
• 60 in / 1500 mm — 20° SIZE 4; 35° SIZE 4; 45° SIZE 5
• 72 in / 1800 mm — 20° SIZE 5; 35° SIZE 5; 45° SIZE 6

CEMA Class E

• 36 in / 900 mm — 20° SIZE 2; 35° SIZE 3; 45° SIZE 3
• 42 in / 1050 mm — 20° SIZE 3; 35° SIZE 4; 45° SIZE 4
• 48 in / 1200 mm — 20° SIZE 4; 35° SIZE 4; 45° SIZE 4
• 54 in / 1350 mm — 20° SIZE 4; 35° SIZE 4; 45° SIZE 4
• 60 in / 1500 mm — 20° SIZE 5; 35° SIZE 5; 45° SIZE 5
• 72 in / 1800 mm — 20° SIZE 5; 35° SIZE 5; 45° SIZE 6
• 84 in / 2100 mm — 20° SIZE 6; 35° SIZE 6; 45° SIZE 6
• 96 in / 2400 mm — 20° SIZE 6; 35° SIZE 6; 45° SIZE 6

Technical specifications

• Series / Model: Belt Support Bar (BSB)
• Manufacturer: Flexco
• Mounting: Pair of BSBs mounts to conveyor structure (four bolts per pair) — no need to lift belt or move idlers
• Wear bars: 1" (25 mm) UHMW
• Adjustability: Telescoping tubing for length adjustment; rotating hinges for approach/bar angles
• Supported troughing angles: 20°, 35°, 45° (angle used depends on belt width and BSB size)
• Available sizes: SIZE 1 through SIZE 6 (covers belt widths from 18 in / 450 mm up to 96 in / 2400 mm)
• CEMA classes: Selection tables provided for CEMA Class C, D and E to determine appropriate BSB size by belt width and trough angle
