Cable terminal stripping and crimping machine JWD-I63PC

automaticservo-driven

This pre-insulated wire ferrule crimping machine is universal for 10 types of wire terminal, It can strip cable wires with different sizes ( 22AWG, 20AWG, 18AWG, 17AWG, 16AWG, 12AWG, 10AWG, 8AWG and 6AWG). It can finish wire stripping, conductors twisting and terminal crimping at one go. • Suitable for crimping loose bulk terminals(preinsulated terminals). • This semi-automatic pre-insulated terminal crimping machine can be set to auto-start or manual mode. Easy to operate. In induction mode, users just need set the parameter and inserting the wire, the machine can automatically strip insulation, twist conductors and crimp the terminal. • This pre-insulated terminal crimping machine has a compact overall structure and is equipped with a vibrating disk inside, which can automatically feed terminals. The enclosed exterior design protects internal components as well as the operator. • JWDI63PC is equipped with a detection system to check the presence of terminals. • Available wire size: 0.3SQMM, 0.5SQMM, 0.75SQMM, 1SQMM, 1.5SQMM, 2.5SQMM, 4SQMM, 6SQMM, 10SQMM, 16SQMM • Available stripping length: 6~30MM • Insulator length of the preinsulated terminal should be less than 7.5mm, Conductor should be length less than 12mm. • Wire range : 0.3 ~ 16SQMM(22AWG~6AWG) • Terminal range : Round tube pre insulated terminal:Insulator length less than 11MM, conductor length less than 20MM • Function : Stripping wire insulation, automatic feed terminal, twist conductors, crimp terminal • Working mode : Inductive triggering /manual triggering • Working speed : 3.2s/pcs bootlace ferrule, preinsulated terminal, tublar terminal crimping machine,
