Wire end ferrules crimping machine JWD-TF1G

cablefor cable terminalsautomatic

• Tubular terminal crimping machine JWD-TF1G can finish stripping wire jacket and crimping(four side crimping) terminals, the crimping length is within 7.5mm . • JWD-TF1G crimp tubular terminal on BVR cables size AWG#20, AWG#19, AWG#18, AWG#17, AWG#16, AWG#15, AWG#14, AWG#13 and AWG#12 (0.5sqmm to 4 sqmm). • Fixtures can be replaced when you need change it. • 1 year warranty • Fast delivery • Technical team support and reliable aftersales service • Machine : Insulated Ferrule Round Tubular Terminal Crimping Machine • Function : wire stripping and automatic tubular terminal crimping • Cable size : BVR rigid cable 0.5sqmm, 0.75sqmm, 1.0sqmm, 1.5sqmm, 2.5sqmm, 4 sqmm • Control system : HMI, electronic control, pneumatic control • Crimped shape : Rectangle crimping(4 side crimping) • Custom made : 2.5 s/pcs • Crimping length max. : 7.5mm • Detection device : Check the terminal exist or not, check the protective device run or not • Gas pressure : 0.6-0.8Mpa clean air source • Environment temperature : 10~20℃ • Environment humidity : 30~80% HR non condensing • Machine dimension : L450mmx W350mm x H400mmDimensions (excluding protrusions)
