Analog I/O module JUMO I/O system analog input module

4-channelcurrentfor RTD

Overview
The JUMO I/O system analog input module provides four individually configurable analog inputs for the JUMO variTRON automation system. Available in a universal-input variant and three additional versions, the slim DIN-rail device is equipped with front PUSH IN terminal strips and connects to operating voltage and system bus by simply plugging modules together for fast installation.

Highlights

• Flexible sensor integration
• AMS2750 and CQI-9 compliant
• Quick startup with PUSH IN terminals

Technical data (table)
General technical data
Inputs: 4 universal analog inputs for RTD sensors (2-/3-/4-wire), thermocouples, standard signals (0(4)-20 mA, 0-1 V, 0-10 V), resistance transmitters; optional high-precision thermocouple, high-speed current/voltage, or RTD-only variants (2/3/4-wire).
Connection: Front PUSH IN terminal strips.
Special features: Each input configurable with two limit-value monitoring functions; configurable module cycle time; switching statuses indicated by LEDs; quick wiring of supply and system bus by plugging modules together; compact design; compatible with JUMO variTRON and earlier JUMO I/O modules (7050xx); optional connection rails increase vibration and shock resistance.
Approvals: DNV; UL.
Voltage supply: DC 24 V (+25/−20 %), supplied via central processing unit with system module 705171 (JUMO variTRON 500) or communication module 3-channel 705163 (JUMO variTRON 300, JUMO variTRON 500 touch, third-party products).
Housing: Plastic housing for DIN-rail mounting in control cabinet.
Protection type: IP20.
Ambient temperature range: -20 to +55 °C.
Dimensions (W × H × D): 12 × 106.7 × 101 mm (without connection elements).

Technical specifications

• Inputs: 4 universal analog inputs supporting RTD (2/3/4-wire), thermocouples, 0(4)-20 mA, 0-1 V, 0-10 V, resistance transmitters; optional high-precision thermocouple or high-speed current/voltage variants
• Connection: Front PUSH IN terminal strips
• Limit value monitoring: Each input configurable with 2 limit-value monitoring functions
• Cycle time: Configurable module cycle time
• Status indication: Switching statuses visualized with LEDs
• Compatibility: For use with JUMO variTRON and earlier JUMO I/O modules (7050xx)
• Approvals: DNV, UL
• Supply voltage: DC 24 V (+25/−20 %), supplied via designated system/communication modules
• Housing: Plastic for DIN-rail mounting
• Protection: IP20
• Operating temperature: -20 to +55 °C
• Dimensions: 12 × 106.7 × 101 mm (without connection elements)
