Impact testing machine HITS-X

transporttensionresistance

Product overview
The HITS-X Series is an impact testing machine for evaluation of dynamic strength (impact properties) of materials and components. The system records maximum test force, energy and displacement at test velocities up to 72 km/h (20 m/s). Two main configurations are offered: HITS-TX (tensile load type) for high-speed tensile and fracture tests, and HITS-PX (punching type) for high-rate puncture and penetration evaluations.

Related Standards

• ISO 6603-2: 2000
• ASTM D3763-06
• ISO/DIS 22183
• ISO 18872

Features

• High test speeds suitable for dynamic impact and high-rate tensile measurements
• Data acquisition of force, energy and displacement for fracture and puncture analysis
• Mechanical design to minimize fixture and inertial artifacts during impact
• Specialized approach jig available for HITS-TX to ensure controlled tensile loading

Applications
Used for high-speed impact and tensile/fracture testing of plastics, composites and metal components. Typical applications include evaluation of recycled plastics, component fracture analysis and high-rate puncture testing. Application notes and case studies are available to support test setup and result interpretation.

Technical specifications

• Maximum velocity: 72 km/h (20 m/s)
• Measured data: maximum test force, energy, displacement
• Available configurations: HITS-TX (tensile load type), HITS-PX (punching type)
• Intended use: high-speed impact testing of materials and parts; tensile and puncture evaluations
• Standards supported: ISO 6603-2, ASTM D3763, ISO/DIS 22183, ISO 18872
