Video extensometer DSES-1000

axiallong-strokeclip-on

Overview
A long-travel contact-type extensometer designed to measure displacement up to specimen breakpoint in tensile tests of rubber and other soft materials. The upper and lower arms clamp to gauge positions with a single operation; each arm independently tracks sample elongation.

Features

• 1000 mm maximum movement distance, enabling elongation measurements up to 4000% (10 mm gauge), 2000% (20 mm), 1600% (25 mm) or 1000% (40 mm). A floating arm mechanism (patent pending) prevents arm disengagement during large elongations.
• ±0.2% relative elongation measurement precision for displacements between 50 mm and 1000 mm, allowing accurate long-distance measurements.
• Lateral quick clamping for easy centering of the extensometer edge with the sample; can be attached to the sample before chucking.

Videos

• DSES-1000 Long-Travel Extensometer for Soft Materials (product movie)

Technical specifications

• Type: Long-travel contact-type extensometer
• Maximum movement distance: 1000 mm
• Elongation capability: up to 4000% (10 mm gauge); 2000% (20 mm); 1600% (25 mm); 1000% (40 mm)
• Measurement precision: ±0.2% relative elongation (for displacements 50–1000 mm)
• Arm mechanism: Floating arm mechanism (patent pending)
• Clamping: Lateral quick clamping; upper and lower arms clamp independently
• Application: Tensile tests of rubber and other soft materials up to specimen breakpoint
