Overview 182 mm P-type silicon wafer designed for semiconductor device fabrication and wafer-level processing. Specified for applications requiring controlled resistivity and minority carrier lifetime.
Key specifications
Type: P-Type Silicon Wafer
Model: SL-M10P
Diameter: 182 mm
Resistivity: 0.4–1.1 Ω·cm
Minority carrier lifetime (MCLT): ≥80 μs
Oxygen concentration: ≤14.5 ppma
Carbon concentration: ≤1 ppma
Material & electrical properties
P-type silicon substrate with specified resistivity range and controlled impurity levels
Minority carrier lifetime (MCLT) ≥80 μs ensures suitability for device fabrication processes sensitive to carrier recombination
Typical applications
Semiconductor device manufacturing (power devices, diodes, MOS processes)
R&D and pilot production in microelectronics
Wafer processing, testing and characterization
Packaging & availability
Supplied in industry-standard packaging; custom packaging and volume ordering available on request
Contact supplier for lead times and batch options
Quality & compliance
Manufactured with controlled oxygen and carbon concentrations as specified
Lot traceability and quality inspection reports available upon request
