Monocrystalline silicon photovoltaic module SL-M10

roof-mounthigh-efficiencyIP68

Overview
Gigalumi SL-M10 is a photovoltaic module designed for commercial and utility-scale installations, offering a nominal power range of 440–460 W and a maximum efficiency of 21.3%.

Information
Cell: P Type Monocrystalline 182×91 mm
No. of cells: 120 cells (6×20)
Rated Maximum Power (Pmax): 460 W
Power range: 440-460 W
Maximum Efficiency: 21.3%
Junction Box: IP68 rated
Maximum System Voltage: 1500 V DC
Operating Temperature: -40℃～+85℃
Connectors: MC4 or MC4 Compatible

Function

• Electricity generation for grid-connected PV systems
• Suitable for rooftop, carport and ground-mounted arrays
• Integration in commercial and utility PV projects

Capacity Range

• Nominal power range: 440–460 W

Driving Sources

• Direct solar irradiance (photovoltaic conversion)
• Compatible with string inverters and central inverters

Technical specifications

• Cell type: P Type Monocrystalline 182×91 mm
• Number of cells: 120 cells (6×20)
• Rated Maximum Power (Pmax): 460 W
• Power range: 440–460 W
• Maximum Efficiency: 21.3%
• Junction Box: IP68 rated
• Maximum System Voltage: 1500 V DC
• Operating Temperature: -40℃ to +85℃
• Connectors: MC4 or MC4 Compatible
